Asus DSL-AX82U User Manual

4
English
Setting up your xDSL routerSetting up your xDSL router
1� Insert your xDSL modem router’s
power adapter to the DCIN port and
plug it to a power outlet�
2� Connect one end of the RJ-11 cable
to the DSL port of your xDSL modem
router, and connect the other end to
the DSL port of your splitter�
3� Turn on your xDSL modem router and
wait for a few minutes for Internet
connection�
4� You can set up your router via wired or wireless connection�
• [Via Wired Connection]
Connect your computer to the router using a wired Ethernet cable�
• [Via Wireless Connection]
Connect to the wireless network with SSID shown on the product
label on the back side of the router�
5� When DSL/WAN LED stops ashing and lights constantly, you can
start the DSL setup process via the QIS Wizard (Quick Internet Setup
Wizard)�
a� Open a web browser and enter http://router�asus�com to launch the
web GUI� Follow onscreen instructions to complete the setup�
b� You can also choose ASUS Router app to
set up your router� Download ASUS Router
App to set up your router via your mobile
devices�
Laptop
Tablet
Smart phone
DSL-AX82U
Power
1
3
Wall telephone outlet
Splitter
Phone
DSL
2
Line
Wall Power Outlet
Laptop
LAN
4
ASUS Router
ASUS
Router

Asus DSL-AX82U Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-45
Modulation	256-QAM, 1024-QAM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	5400 Mbit/s
VPN server	Server IPSec, Server OVPN, Server PPTP
VPN support	- VPN Client L2PT - VPN Client OVPN - VPN Client PPTP - VPN Server IPSec - VPN Server OVPN - VPN Server PPTP
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Security algorithms	WPS
Cables included	LAN (RJ-45), Phone (RJ-11)
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
Storage temperature (T-T)	0 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	20 - 90 %
Operating relative humidity (H-H)	50 - 90 %
Power source type	DC
Product type	Tabletop router
Product color	Black
LED indicators	DSL, Power, WAN, WPS
Package depth	317 mm
Package width	365 mm
Package height	99 mm
Package weight	1700 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	184 mm
Width	276 mm
Height	65 mm
Weight	572 g
