Asus DSL-N12E Quick Start Guide

Magyar
1. Csatlakoztassa az eszközöket.
2. Az ADSL beállítások előtt győződjön meg arról, hogy a DSL-N12E felső panelján található
ADSL visszajelző folyamatos világításra váltott-e.
3. Írja be a webböngésző címsávjába a http://192.168.1.1 értéket. Az előugró ablakban adja
meg a felhasználónevet és a jelszót (felhasználónév/jelszó: admin/admin). Megjelenik a
gyors internetbeállítási (QIS) varázsló.
* Ha a QIS weblap nem jelenik meg a böngészőprogram indítása után, tiltsa le a
böngészőprogram proxy-beállításait.
4. A gyors internetbeállítási varázsló 1-4. lépésénél adja meg a szükséges adatokat az egyes
oldalakon, majd kattintson a Next (Tovább) gombra.
5. Az 5. lépésnél megjelenő Configuration Saving (Konfiguráció mentése) oldalon kattintson a
Finish (Befejezés) gombra a kongurációs beállítások mentéséhez és a beállítás befejezéséhez.
Slovensky
1. Pripojte svoje zariadenia.
2. Skôr, ako spustíte postup nastavenia ADSL skontrolujte, či indikátor ADSL na hornom paneli
DSL-N12E svieti neprerušovane.
3. Vo vašom internetovom vyhľadávači zapíšte http://192.168.1.1. V prekrývacom okne zapíšte
užívateľské meno a heslo (užívateľské meno/heslo: správca/správca). Zobrazí sa sprievodca
Quick Internet Setup (QIS) (Rýchle nastavenie internetu).
* Pokiaľ sa webová stránka QIS nezobrazí po spustení internetového prehliadača,
deaktivujte proxy nastavenia internetového prehliadača.
4. V možnosti Quick Internet Setup (QIS) (Rýchle nastavenie internetu) vpíšte v krokoch č. 1 až
5 na každej stránke potrebné informácie a kliknite na tlačidlo Next (Ďalej).
5. IV kroku č. 5: Nastavenia kongurácie uložte kliknutím na tlačidlo Finish (Dokončiť) na
stránke Conguration Saving (Uložiť konguráciu) a dokončite proces nastavovania.
Manufacturer
ASUSTeK Computer Inc.
Tel: +886-2-2894-3447
Address: No. 150, LI-TE RD., PEITOU, TAIPEI 112, TAIWAN
Authorised representative in Europe
ASUS Computer GmbH
Address: HARKORT STR. 21-23, 40880 RATINGEN, GERMANY
Authorised distributors in Turkey
BOGAZICI BIL GISAYAR SAN. VE TIC. A.S.
Tel: +90 212 3311000
Address: AYAZAGA MAH. KEMERBURGAZ CAD. NO.10 AYAZAGA/ISTANBUL
CIZGI Elektronik San. Tic. Ltd. Sti.
Tel: 0090 2123567070
Address: CEMAL SURURI CD. HALIM MERIC IS MERKEZI No:15/C D: 5-6 34394 MECIDIYEKOY/
ISTANBUL
EEE Yönetmeliğine Uygundur.
Česky
1. Připojte zařízení.
2. Před zahájením postupu nastavení ADSL zkontrolujte, zda indikátor ADSL na horní panelu
zařízení DSL-N12E svítí.
3. Ve webovém prohlížeči zadejte adresu http://192.168.1.1. V místním okně zadejte uživatelské jméno a
heslo (uživatelské jméno/heslo: admin/admin). Zobrazí se průvodce Rychlé nastavení Internetu (QIS).
* Pokud se po spuštění webového prohlížeče nezobrazí webová stránka QIS, deaktivujte
nastavení proxy webového prohlížeče.
4. V krocích 1 až 4 Rychlého nastavení Internetu (QIS) zadejte na každé stránce nezbytné
informace a klepněte na tlačítko Další.
5. V kroku 5: stránka Uložení kongurace klepnutím na tlačítko Dokončit uložte nastavení
kongurace a dokončete konguraci.
Suomi
1. Kytke laitteet.
2. Varmista ennen ADSL:n asennusta, että ADSL-ilmaisin DSL-N12E:n yläpaneelissa on
yhtenäinen.
3. Näppäile web-selaimen osoiteriville http://192.168.1.1. Näppäile ponnahdusikkunassa käyttäjänimi ja
salasana (käyttäjänimi/salasana: admin/admin). Ohjattu pika-internet-asetus (QIS) tulee näkyviin.
* Jos QIS-verkkosivu ei tule näkyviin verkkoselaimen käynnistämisen jälkeen, ota
verkkoselaimen proxy-asetus pois päältä.
4. Täytä pika-internet-asetusten (QIS) vaiheissa 1–4 kullakin sivulla pyydetyt tiedot ja napsauta
Next (Seuraava) -painiketta.
5. Vaiheessa 5: Napsauta määritysten tallennussivulla Finish (Lopeta) -painiketta tallentaaksesi
määritysasetukset ja päättääksesi asetuksen.
Nederlands
1. Sluit uw apparaten aan.
2. Voordat u begint met het instellen van de ADSL, moet u controleren of de ADSL-indicator op
het DSL-N12E van het bovenste paneel stabiel brandt.
3. Ga met de webbrowser naar http://192.168.1.1. Geef in het venstertje gebruikersnaam en
wachtwoord op (gebruikersnaam/wachtwoord: admin/admin). De wizard Quick Internet
Setup (QIS) verschijnt.
* Als de QIS-webpagina niet verschijnt nadat u de webbrowser hebt gestart, moet u de
proxy-instellingen van de webbrowser uitschakelen.
4. In stappen 1 tot en met 4 van de Quick Internet Setup (QIS) geeft u de vereiste gegevens op.
Klik op Next.
5. In Stap 5: de pagina Conguration Saving, klikt u op Finish om de conguratie-instellingen
op te slaan en de instelling te voltooien.
Български
1. Свържетеустройствата.
2. ПредидазапочнетепроцедуратапонастройканаADSL,уверетесе,чеADSLиндикаторътна
горнияпанелнаDSL-N12Eсветинепрекъснато.
3. Въведете http://192.168.1.1.в своя уеб браузър. В изскачащия прозорец въведете
потребителското име и парола (потребителско име/парола: admin/admin). Появява се
съветник за бърза настройка на интернет (QIS).
* АкоуебсайтътQISнесепоявиследкатостестартиралиуеббраузъра,деактивирайте
настройкитенапроксисървъранауеббраузъра.
4. В стъпки от 1 до 4 на бързата настройка на интернет (QIS) попълнете необходимата
информация на всяка страница и натиснете Next (Напред).
5. Стъпка 5: Страница за запис на конфигурацията. Щракнете върху Finish (Край), за да
запишете конфигурацията и да приключите настройката.
Ελληνικά
1. Συνδέστε τις συσκευές σας.
2. Πριν ξεκινήσετε τη διαδικασία ρύθμισης του ADSL, βεβαιωθείτε ότι η λυχνία ένδειξης ADSL
στην άνω πλευρά του DSL-N12E είναι σταθερή.
3. Στο πρόγραμμα περιήγησης στο διαδίκτυο, πληκτρολογήστε http://192.168.1.1. Στο
αναδυόμενο παράθυρο, πληκτρολογήστε το όνομα χρήστη και τον κωδικό πρόσβασης
(όνομα χρήστη/κωδικός πρόσβασης: admin/admin). Εμφανίζεται ο Οδηγός Γρήγορης
Εγκατάστασης Internet (QIS - Quick Internet Setup).
* Αν η ιστοσελίδα QIS (Γρήγορη Ρύθμιση Internet) δεν εμφανιστεί αφού εκκινήσετε το
πρόγραμμα περιήγησης στο διαδίκτυο, απενεργοποιήστε τις ρυθμίσεις του διακομιστή
μεσολάβησης από το πρόγραμμα περιήγησης στο διαδίκτυο.
4. Στα βήματα 1 έως 4 του Οδηγού QIS, συμπληρώστε τις απαραίτητες πληροφορίες σε κάθε
σελίδα και κάντε κλικ στο Επόμενο.
5. Στο Βήμα 5: Στη σελίδα αποθήκευσης ρυθμίσεων διαμόρφωσης, κάντε κλικ στο Τέλος για να
αποθηκεύσετε τις ρυθμίσεις και να ολοκληρώσετε την εγκατάσταση.
Türkçe
1. Aygıtlarınızı bağlayın.
2. ADSL ayar prosedürüne başlamadan önce, DSL-N12E üst panelindeki ADSL göstergesinin
sürekli yandığından emin olun.
3. Açılır pencerede, kullanıcı adını ve parolayı girin (kullanıcı adı/parola: admin/admin).
Hızlı İnternet Kurulumu (QIS) sihirbazı belirir.
* QIS web sayfası, web tarayıcınız başlatıldıktan sonra ekrana gelmiyorsa, web tarayıcınızın
proxy ayarlarını devre dışı bırakın.
4. Hızlı İnternet Kurulumunda (QIS) adım 1’den 4’e kadar, her sayfadaki gerekli bilgileri
doldurun ve İleri’ye tıklayın.
5. 5. Adımda: Yapılandırma Kaydetme sayfasında, yapılandırma ayarlarını kaydetmek için Bitir’e
tıklayın ve kurulumu tamamlayın.
Bahasa Malaysia
1. Sambungkan peranti anda.
2. Sebelum memulakan prosedur penetapan ADSL, sila pastikan bahawa penunjuk ADSL pada
DSL-N12E dari panel atas menjadi padu.
3. Dalam penyemak imbas web anda, masukkan http://192.168.1.1. Dalam tetingkap
pop timbul, masukkan nama pengguna dan kata laluan (nama pengguna/kata laluan:
pentadbir/pentadbir). Wizard Persediaan Internet Cepat (QIS) muncul.
* Jika laman web QIS tidak muncul setelah anda melancarkan web browser, mematikan
tetapan proksi pada web browser.
4. Dalam langkah 1 hingga 4 Persediaan Internet Cepat (QIS), masukkan maklumat yang
perlu dalam setiap halaman dan klik Seterusnya.
5. Dalam Langkah 5: Halaman Penyimpanan Kongurasi, klik Selesai untuk menyimpan
tetapan kongurasi dan lengkapkan persediaan.
