Chapter 2: BIOS information 2-15
CPU Offset Voltage [Auto]
Allows you to set the CPU Offset voltage. The values range from 0.003125V to 0.500V
with a 0.003125V interval.
Refer to the CPU documentation before setting the CPU voltage. Setting a high voltage
may damage the CPU permanently, and setting a low voltage may make the system
unstable.
VDDNB Offset Mode Sign [+]
[+] To offset the voltage by a positive value.
[–] To offset the voltage by a negative value.
VDDNB Offset Voltage [Auto]
Allows you to set the VDDNB Offset voltage. The values range from 0.003125V to
0.500V with a 0.003125V interval.
2.4.8 DRAM Voltage [Auto]
Allows you to set the DRAM voltage. The values range from 1.35V to 2.30V with a 0.01V
interval.
2.4.9 SB 1.1V Voltage [Auto]
Allows you to set the Southbridge 1.1V voltage. The values range from 1.1V to 1.4V with a
0.01V interval.
2.4.10 1.1Vsb Voltage [Auto]
Allows you to set the 1.1Vsb voltage. The values range from 1.1000V to 1.2000V with a 0.1V
interval.
2.4.11 APU1.2V Voltage [Auto]
Allows you to set the APU (Accelerated Processor Unit) 1.2V voltage. The values range from
1.2000V to 1.8000V with a 0.01V interval.
2.4.12 VDDA Voltage [Auto]
Allows you to set the VDDA voltage. The values range from 2.5000V to 2.8000V with a 0.1V
interval.
• The values of the CPU Offset Voltage, VDDNB Offset Voltage, DRAM Voltage, SB
1.1V Voltage, 1.1Vsb Voltage, APU1.2V Voltage, and VDDA Voltage items are labeled
in different color, indicating the risk levels of high voltage settings.
• The system may need better cooling system to work stably under high voltage settings.
2.4.13 APU Spread Spectrum [Auto]
[Auto] Automatic conguration.
[Disabled] Enhances the overclocking ability.
[Enabled] Sets to [Enabled] for EMI control.
