Knowing the Parts
Right Side
1
2
3
ExpressCard Slot
One 26pin Express card slot is available to support one
ExpressCard/34mm expansion card. This new interface
is faster by using a serial bus supporting USB 2.0 and PCI
Express instead of the slower parallel bus used in the PC
card slot. (Not compatible with previous PCMCIA cards.)
Wireless Switch
Enables or disables the built-in wireless LAN and Bluetooth
(selected models). When enabled, the wireless status
indicator will light. Windows software settings are necessary
before use.
SPDIF Output Jack
This jack provides connection to SPDIF (Sony/Philips Digital
Interface) compliant devices for digital audio output. Use
this feature to turn the Notebook PC into a hi-fi home
entertainment system.
Headphone Output Jack
The stereo headphone jack (1/8 inch) is used to connect
the Notebook PC’s audio out signal to amplified speakers
or headphones. Using this jack automatically disables the
built-in speakers.
To Next Page
