ASUS H110-PLUS
1-3
4. Holddownthe<Del>keyduringthebootprocessand
enterBIOSsetuptore-enterdata.
Ifthestepsabovedonothelp,removetheonboardbatteryand
shortthetwopinsagaintocleartheCMOSRTCRAMdata.
AfterclearingtheCMOS,reinstallthebattery.
Speaker connector (4-pin SPEAKER)
This4-pinconnectorisforthechassis-mountedsystemwarningspeaker.The
speakerallowsyoutohearsystembeepsandwarnings.
Intel
®
H110 Serial ATA 6.0Gb/s connectors (7-pin SATA6G_1~4)
TheseconnectorsconnecttoSerialATA6.0Gb/sharddiskdrivesviaSerialATA
6.0Gb/ssignalcables.
Whenusinghot-plugandNCQ,settheSATA Mode SelectionitemintheBIOSto
[AHCI].
System panel connector (10-1 pin PANEL)
Thisconnectorsupportsseveralchassis-mountedfunctions.
USB 3.0 connector (20-1 pin USB3_12)
ConnectaUSB3.0moduletothisconnectorforadditionalUSB3.0frontorrear
panelports.ThisconnectorcomplieswithUSB3.0specicationsandprovide
fasterdatatransferspeedsofupto5Gbps,fasterchargingtimeforUSB-
chargeabledevices,optimizedpowerefciency,andbackwardcompatibilitywith
USB2.0.
USB 2.0 connectors (10-1 pin USB56, USB910)
ConnecttheUSBmodulecabletoanyoftheseconnectors,theninstallthemodule
toaslotopeningatthebackofthesystemchassis.TheseUSBconnectorscomply
withUSB2.0specicationsandsupportupto480Mbpsconnectionspeed.
Serial port connector (10-1 pin COM)
Connecttheserialportmodulecabletothisconnector,theninstallthemoduletoa
slotopeningatthebackofthesystemchassis.
Digital audio connector (4-1 pin SPDIF_OUT)
ConnecttheS/PDIFOutmodulecabletothisconnector,then
installthemoduletoaslotopeningatthebackofthesystem
chassis
SPDIF_OUT
+5V SPDIFOUT GND
PIN 1
CLRTC
+3V_BAT GND
PIN 1
