The following item appears only when you set the CPU Core Voltage Mode to [Offset
Mode].
Offset Mode Sign [+]
[+] To offset the voltage by a positive value.
[–] To offset the voltage by a negative value.
CPU Graphics Voltage Offset [Auto]
This item allows you to congure the CPU Graphics Voltage Offset. Use the <+> or <-> keys
to adjust the value. The values range from 0.001V to 0.635V with a 0.005V interval.
2.5.20 PCH Core Voltage [Auto]
This item allows you to set the PCH core voltage. Conguration options: [Auto] [1.00V]
[1.05V] [1.10V] [1.15V]
2.5.21 DRAM REF Voltage Control
DRAM CTRL REF Voltage [Auto]
Allows you to set the DRAM reference voltage on the control lines. You can use the <+> or
<-> keys to adjust the value. The values range from 0.39500V to 0.63000V with a 0.00500V
interval.
DRAM DATA REF Voltage on CHA [Auto]
Allows you to set the DRAM reference voltage on the data lines of channel A. You can use
the <+> or <-> keys to adjust the value. The values range from 0.39500V to 0.63000V with a
0.00500V interval.
DRAM DATA REF Voltage on CHB [Auto]
Allows you to set the DRAM reference voltage on the data lines of channel B. You can use
the <+> or <-> keys to adjust the value. The values range from 0.39500V to 0.63000V with a
0.00500V interval.
ASUS H170M-E D3 2-25
