1.3.3 Motherboard layout
H61M-E
PCIEX16
PCIEX1_1
PCIEX1_2
F_PANEL
SPEAKER
CLRTC
USB78 USB910USB56
AAFP
ATX12V
EATXPWR
CPU_FAN
CHA_FAN
Lithium Cell
CMOS Power
Super
I/O
ALC
887
RTL
8111F
RT
8876
64Mb
BIOS
SB_PWR
22.6cm(8.9in)
LGA1155
Intel
®
H61
DDR3 DIMM_A1 (64bit, 240-pin module) DDR3 DIMM_B1 (64bit, 240-pin module)
SATA3G_1 SATA3G_2
SATA3G_3 SATA3G_4
AUDIO
KBMS
LAN_USB12
USB34
17.5cm(6.9in)
VGA
321 41
6
2
7891011
5
KBPWR
USBPW1-4
USBPW5-10
12
12
13
