The following two items appear only when you set the OnChip SATA Channel
item to [Enabled].
SATA Port1 - Port4 [IDE]
Sets the conguration for the Serial ATA connectors supported by the Southbridge
chip. Conguration options: [IDE] [RAID] [AHCI]
• If you want to use the Serial ATA hard disk drives as Parallel ATA physical
storage devices, keep the default setting [IDE].
• If you want to create RAID sets with the PROMISE
®
RAID utility from the
Serial ATA hard disk drives, set this item to [RAID].
• If you want the Serial ATA hard disk drives to use the Advanced Host
Controller Interface (AHCI), set this item to [AHCI]. The AHCI allows
the onboard storage driver to enable advanced Serial ATA features that
increases storage performance on random workloads by allowing the drive
to internally optimize the order of commands.
• When this item is set [AHCI], the information of the SATA connectors 1–6
can be seen only under the OS environment or during POST.
SATA Port5 - Port6 [IDE]
Setting this item to [IDE] instead of [RAID] or [AHCI] allows the system to
recognize the optical dirves connected to the SATA connectors 5 or 6 when
installing OS.
If you use a SATA optical drive to run the OS installation disk, we strongly
recommend that you install the optical dirve to the SATA connectors 5/6 and set
them to [IDE] mode.
4.3.5 System Information
This menu gives you an overview of the general system specications. The BIOS
automatically detects the items in this menu.
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
BIOS SETUP UTILITY
Main
BIOS Information
Version :0702
Build Date :10/21/10
Processor
Type :AMD Opteron(tm) Processor 6168
Speed :1900MHZ
System Memory
Usable Size : 2047MB
System Memory Information
←→ Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
