Asus KGPE-D16 User Manual

4-28 Chapter 4: BIOS setup
The
USB Devices Enabled
item shows the auto-detected values. If no USB
device is detected, the item shows
None
.
Legacy USB Support [Enabled]
Allows you to enable or disable support for legacy USB devices. Setting to [Auto]
allows the system to detect the presence of USB devices at startup. If detected, the
USB controller legacy mode is enabled. If no USB device is detected, the legacy
USB support is disabled. Conguration options: [Disabled] [Enabled] [Auto]
USB 2.0 Controller Mode [HiSpeed]
Allows you to set the USB 2.0 controller to HiSpeed (480Mbps) or FullSpeed
(12Mbps). Conguration options: [FullSpeed] [HiSpeed]
BIOS EHCI Hand-Off [Enabled]
Enables or disables the BIOS EHCI hand-off support.
Conguration options: [Disabled] [Enabled]
The following item appears only when you set
Legacy USB Support
to
[Enabled] and [Auto].
Legacy USB1.1 HC Support [Enabled]
This item appears only when you set Legacy USB Support to [Enabled], and allows
you to congure the Legacy USB1.1 HC support.
Conguration options: [Disabled] [Enabled]
4.4.4 USB Conguration
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
USB Conguration
Module Version - 2.24.5-13.4
USB Devices Enabled :
None
Legacy USB Support [Enabled]
USB 2.0 Controller Mode [HiSpeed]
BIOS EHCI Hand-Off [Enabled]
Legacy USB1.1 HC Support [Enabled]
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Enables support for
legacy USB. AUTO
option disables
legacy support if
no USB devices are
connected.

Asus KGPE-D16 Specifications

General

Form Factor	SSI EEB
Maximum Memory Supported	128GB
PCIe 2.0 x16 Slots	2
PCIe 2.0 x4 Slots	1
PCI Slots	1
SATA 3Gb/s Ports	6
CPU Socket	Socket G34
Chipset	AMD SR5690
Memory Slots	16
Memory Type	DDR3
PCIe 2.0 x8 Slots	1
USB Ports	6
Network	Dual Gigabit LAN
