Asus M2N-SLI User Manual

1-6 Chapter 1: Product introduction
Precision Tweaker
This feature allows you to ne tune the CPU/memory voltage and gradually
increase the memory Front Side Bus (FSB) and PCI Express frequency at 1MHz
increment to achieve maximum system performance.
C.P.R. (CPU Parameter Recall)
The C.P.R. feature of the motherboard BIOS allows automatic re-setting to the
BIOS default settings in case the system hangs due to overclocking. When the
system hangs due to overclocking, C.P.R. eliminates the need to open the system
chassis and clear the RTC data. Simply shut down and reboot the system, and the
BIOS automatically restores the CPU default setting for each parameter.
1.3.4 ASUS Intelligent Overclocking features
ASUS BIOS Prole
The motherboard features the ASUS BIOS Prole that allows users to conveniently
store or load multiple BIOS settings. The BIOS settings can be stored in the
CMOS or a separate le, giving users freedom to share and distribute their favorite
settings.
AI NOS™ (Non-Delay Overclocking System)
ASUS Non-delay Overclocking System™ (NOS) is a technology that auto-detects
the CPU loading and dynamically overclocks the CPU speed only when needed.
See page 4-20 for details.

Asus M2N-SLI Specifications

General

Chipset	NVIDIA nForce 560 SLI
CPU Socket	Socket AM2
Memory Type	DDR2
Max Memory	8GB
Memory Standard	DDR2 800/667/533
SLI Support	Yes
Form Factor	ATX
PCI Express x16	2
PCI Express x1	2
PCI Slots	3
SATA	4 x SATA 3Gb/s
Audio Chipset	Realtek ALC883
LAN Chipset	Marvell 88E1116
Max. LAN Speed	10/100/1000Mbps
PS/2	2
CPU Type	Athlon 64 / Athlon 64 FX / Athlon 64 X2 / Sempron
Memory Slots	4
SATA RAID	0/1/0+1/5
Audio Channels	8
USB 1.1/2.0	4 x USB 2.0
