Asus M4A78LT-M LX User Manual

DDR3-1333 MHz capability
Vendor Part No. Size
SS/
DS
Brand Chip NO.
Timing
DIMM
(BIOS)
Voltage
DIMM
Support
A* B*
G.SKILL F3-10600CL8D-2GBHK 1024MB SS G.SKILL Heat-Sink Package •
G.SKILL F3-10600CL9D-2GBPK 1024MB SS G.SKILL Heat-Sink Package • •
G.SKILL F3-10666CL7T-3GBPK 3072MB(Kit of 3) SS N/A Heat-Sink Package 7-7-7-18 1.5~1.6V • •
G.SKILL F3-10666CL9T-3GBNQ 3072MB(Kit of 3) SS N/A Heat-Sink Package 9-9-9-24 1.5~1.6V • •
G.SKILL F3-10600CL7D-2GBPI 1024MB DS G.SKILL Heat-Sink Package • •
G.SKILL F3-10600CL9D-2GBNQ 1024MB DS G.SKILL Heat-Sink Package •
G.SkiLL F3-10666CL8D-4GBHK 4096MB(Kit of 2 ) DS N/A Heat-Sink Package 8-8-8-21 1.5-1.6V • •
G.SKILL F3-10666CL7T-6GBPK 6144MB(Kit of 3 ) DS N/A Heat-Sink Package 7-7-7-18 1.5~1.6V • •
G.SKILL F3-10666CL9T-6GBNQ 6144MB(Kit of 3) DS N/A Heat-Sink Package 9-9-9-24 1.5V~1.6V • •
GEIL DDR3-1333 CL9-9-9-24 1024MB SS N/A Heat-Sink Package 9 • •
GEIL GV34GB1333C7DC 2048MB DS N/A Heat-Sink Package 7-7-7-24 1.5V • •
GEIL GG34GB1333C9DC 4096MB(Kit of 2) DS GEIL GL1L128M88BA12N 9-9-9-24 1.3V(low
voltage)
• •
GEIL DDR3-1333 CL9-9-9-24 6144MB(Kit of 3 ) DS N/A Heat-Sink Package 9 1.5V • •
Kingmax FLFD45F-B8MH9 MAES 1024MB SS Micron 9CF22D9KPT • •
Kingmax FLFE85F-B8MF9 2048MB DS Micron 8HD22D9JNM • •
Kingmax FLFE85F-B8MH9 MEES 2048MB DS Micron 9GF27D9KPT • •
Kingston KVR1333D3N9/1G 1024MB SS Hynix H5TQ1G83BFR 9 1.5V • •
Kingston KVR1333D3N9/2G 2048MB DS Qimonda IDSH1G-03A1F1C-13H 1.5V • •
Micron MT8JTF12864AY-1G4D1 1024MB SS Micron 8LD22D9JNM • •
Micron MT8JTF12864AZ-1G4F1 1024MB SS Micron 9FF22D9KPT 9 • •
Micron MT9JSF 12872AZ-1G4F1 1024MB SS Micron 91F22D9KPT(ECC) 9 • •
Micron MT8JTF12864AY-1G4D1 3072MB(Kit of 3) SS Micron 8XD22D9JNM 9 • •
Micron MT12JSF25672AZ-1G4F1 2048MB DS Micron 91F22D9KPT(ECC) 9 • •
Micron MT16JTF25664AY-1G1D1 2048MB DS Micron 8LD22 D9JNM • •
Micron MT18JTF25664AZ-1G4F1 2048MB DS Micron 9KF27D9KPT 9 • •
Micron MT16JTF25664AY-1G4D1 6144MB(Kit of 3 ) DS Micron 8UD22D9JNM 9 • •
OCZ OCZ3X1333LV3GK(XMP) 3072MB(Kit of 3) SS N/A Heat-Sink Package 1.6V •
OCZ OCZ3G13334GK 4096MB(Kit of 2) DS N/A Heat-Sink Package 1.7V • •
OCZ OCZ3P13334GK 4096MB(Kit of 2) DS N/A Heat-Sink Package 7-7-7-20 1.8V • •
OCZ OCZ3G1333LV6GK 6144MB(Kit of 3 ) DS N/A Heat-Sink Package 9-9-9-20 1.65V • •
OCZ OCZ3P1333LV6GK 6144MB(Kit of 3 ) DS N/A Heat-Sink Package 7-7-7-20 1.65V • •
OCZ OCZ3X1333LV6GK(XMP) 6144MB(Kit of 3 ) DS N/A Heat-Sink Package 8-8-8-20 1.60V • •
SAMSUNG M378B2873DZ1-CH9 1024MB SS Samsung K4B1G0846D-HCH9 • •
SAMSUNG M378B2873DZ1-CH9 1024MB SS Samsung SEC 846 HCH9 K4B1G08460 • •
SAMSUNG M378B2873EH1-CH9 1024MB SS Samsung SEC 913 HCH9 K4B1G0846E • •
SAMSUNG M391B2873DZ1-CH9 1024MB SS Samsung K4B1G0846D-HCH9(ECC) • •
SAMSUNG M378B5673DZ1-CH9 2048MB DS Samsung K4B1G0846D-HCH9 • •
SAMSUNG M378B5673EH1-CH9 2048MB DS Samsung SEC 913 HCH9 K4B1G0846E • •
SAMSUNG M391B5673DZ1-CH9 2048MB DS Samsung K4B1G0846D-HCH9(ECC) • •
Super Talent W1333X2GB8 1024MB SS N/A Heat-Sink Package • •
Transcend TS128MLK64V3U 1024MB SS N/A SEC 813HCH9 K4B1G0846D • •
Transcend TS128MLK72V3U 1024MB SS N/A K4B1G0846D(ECC) • •
Transcend TS256MLK64V3U 2048MB DS Micron 9GF27D9KPT • •
Transcend TS256MLK64V3U 2048MB DS N/A SEC816HCH9K4B1G0846D • •
Chapter 1: Product introduction1-14

Asus M4A78LT-M LX Specifications

General

ECC	Yes
Memory channels	Dual-channel
Number of memory slots	2
Maximum internal memory	8 GB
Supported memory clock speeds	1066, 1333, 1600, 1866 MHz
Processor socket	Socket AM3
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II X2, AMD Phenom II X4, AMD Phenom II X6
USB 2.0 connectors	3
Number of SATA connectors	6
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	4
Audio chip	Realtek ALC887
Component for	PC
Power source type	ATX
Motherboard chipset	AMD 760G
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Motherboard southbridge	AMD SB710
Compatible operating systems	DOS Windows XP Windows XP 64bit Windows Vista 32bit Wnindows Vista 64bit Windows 7 Windows 7 64bit
Graphics card	Radeon 3000
Maximum graphics card memory	1024 MB
Parallel processing technology support	Hybrid CrossFireX
RAID levels	0, 1, 10, JBOD
Controller interface type	SATA 3.0 Gb/s
Cables included	SATA
Bundled software	ASUS PC Probe II ASUS Update
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	203 mm
Width	244 mm
