ix
M4A87TD specications summary
(continued on the next page)
CPU AMD
®
Socket AM3 for AMD
®
Phenom™ II / Athlon™ II /
Sempron™ 100 Series ProcessorsSempron™ 100 Series Processors
AMD
®
140W CPU Support
AMD
®
Cool ‘n’ Quiet™ 2.0 Technology (by CPU type)
Supports 45nm CPU
Chipset
AMD
®
870 / SB850
System bus Up to 5200 MT/s; HyperTransport™ 3.0 interface
Memory
4 x DIMM, max. 16 GB, DDR3 2000(O.C.)/ 1600 / 1333 /
1066 MHz ECC / non-ECC, un-buffered memory
Dual-channel memory architecture
DDR3 Memory Ultra Low Voltage support
* Due to the CPU spec., AMD AM3 100 and 200 series
CPUs support up to DDR3 1066MHz. With ASUS design,
this motherboard can support up to DDR3 1333MHz.
** Due to OS limitation, when installing total memory of 4GB
capacity or more, Windows
®
32-bit operating system may
only recognize less than 3 GB. Install a 64-bit Windows
®
OS when you want to install 4GB or more memory on the
motherboard.
*** Refer to www.asus.com or this user manual for the
Memory QVL (Qualied Vendors Lists)
Expansion slots
1 x PCIe 2.0 x16 slot
1 x PCIe 2.0 x4 slot
1 x PCIe 2.0 x1 slot
3 x PCI slots
Storage SB850 chipet:
- 6 x SATA 6Gb/s supporting RAID 0, 1, 5, and 10
JMicron
®
JMB368 SATA & PATA controllers:
- 1 x UltraDMA 133/100 for up to 2 PATA devices
LAN
RTL8111E PCIe Gigabit LAN controller featuring AI NET 2
Audio
VIA
®
VT1818 8-channel High Denition Audio CODEC
- Blu-ray disc audio layer Content Protection
- Supports Jack-Detection, Multi-Streaming and Front
Panel Jack-Retasking
- Optical S/PDIF Out port at back I/O
- ASUS Noise Filter
USB NEC USB3 controller: (only for USB3 Edition)
- 2 x USB 3.0 ports (blue at back panel)
SB850 chipset:
- 14(12) x USB 2.0 ports (6 ports at midboard; 8(6) ports at
back panel) (12 ports for USB3 Edition)
