Asus MAXIMUS IV GENE-Z User Manual

ROG Maximus IV GENE-Z 3-31
Fan Speed Monitor
CPU FAN; Chassis FAN1/2/3 Speed; CPU FAN OPT Speed [xxxxRPM] or
[Ignored] / [N/A]
The onboard hardware monitor automatically detects and displays the CPU
fan, chassis fan, and optional fan speed in rotations per minute (RPM). If any
of the fans is not connected to the motherboard, the eld shows [N/A]. These
items are not user-congurable.
Fan Speed Control
CPU Q-Fan Control [Disabled]
Allows you to enable or disable the CPU fan controller.
[Disabled] Disables the CPU Q-fan controller.
[Enabled] Enables the CPU Q-fan controller.
The following three items appear when you enable the CPU Fan Control
feature.
CPU Fan Speed Low Limit [600 RPM]
Allows you to set the low speed limit of the CPU fan and the system sends
warning message when the fan speed drops below the set value.
Conguration options: [Ignored] [200 RPM] [300 RPM] [400 RPM] [500 RPM]
[600 RPM]
CPU Fan Profile [Standard]
Allows you to set the appropriate performance level of the CPU fan.
[Standard] Sets to [Standard] to make the chassis fan automatically adjust
depending on the CPU temperature.
[Silent] Sets to [Silent] to minimize the fan speed for quiet CPU fan
operation.
[Turbo] Set to [Turbo] to achieve maximum CPU fan speed.
[Manual] Sets to [Manual] to display more items for you to manually
adjust the CPU upper/lower temperature, and CPU fan upper/
lower duty cycle.
The following four items appear only when you set  to
[Manual].
CPU Upper Temperature [70]
Use the <+> and <-> keys to adjust the upper limit of the CPU temperature. The
values range from 20ºC to 75ºC.

Asus MAXIMUS IV GENE-Z Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Number of memory slots	4
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1200, 1300, 1333, 1600, 1800, 1866, 2133, 2200 MHz
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
USB 2.0 connectors	2
Number of EATX power connectors	1
Number of Parallel ATA connectors	0
Headphone outputs	6
USB 2.0 ports quantity	8
Component for	PC
Power source type	ATX
Motherboard chipset	Intel Z68
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows XP, Vista, 7 32/64-bit
PCI Express slots version	2.0
Maximum graphics card memory	1759 MB
Manageability features	WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE
RAID levels	0, 1, 5, 10
Networking features	10/100/1000 Mbit/sec
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Width	- mm
