Asus P11C-M/4L - NGFF) Connectors (NGFF1-2); Thermal Sensor Cable Connector (3-Pin TR1)

2-38
Chapter 2: Hardware Information
16. M.2 (NGFF) connectors (NGFF1-2)
These connectors allow you to install M.2 devices.
Theseconnectorssupporttype2242/2260/2280/22110devicesonbothPCIex2and
SATAinterface.
The M.2 (NGFF) device is purchased separately
17. Thermal sensor cable connector (3-pin TR1)
This connector allows you to connect a thermal sensor cable that is used for monitoring
temperature.Connectthethermalsensorcabletotheconnectorandplaceitsprobeto
the device that you want to monitor.
