ASUS P11C-M/4L
4-35
Setup Prompt Timeout [1]
Allowsyoutosetthenumberofsecondsthatthermwarewaitsbeforeinitiatingtheoriginal
defaultbootselection.65535(OxFFFF)meansindenitewaiting.Usethe<+>or<->toadjust
the value.
Bootup NumLock State [On]
Allowsyoutoselectthepower-onstatefortheNumLock.
Congurationoptions:[Off][On]
Quiet Boot [Disabled]
Allows you to enable or disable Quiet Boot option.
Congurationoptions:[Disabled][Enabled]
Boot Option Priorities
These items specify the boot device priority sequence from the available devices. The
number of device items that appears on the screen depends on the number of devices
installed in the system.
• Toselectthebootdeviceduringsystemstartup,press<F8>whenASUSLogo
appears.
• ToaccessWindowsOSinSafeMode,pleasepress<F8>afterPOST.
Fast Boot [Disabled]
Allows you to enable or disable boot with initialization of a minimal set of devices required to
launch active boot option. This has no effect for BBS boot options.
Congurationoptions:[Disabled][Enabled]
The following item appears only when you set Fast Boot to [Enabled].
Sata Support [All Sata Devices]
[LastBootHDDOnly] OnlylastbootedHDDdevicewillbeavailableinPOST.
[AllSataDevices]  AllSATAdeviceswillbeavailableinOSandPOST.
VGA Support [EFI Driver]
[Auto] OnlylegacyOpRomwithLegacyOS,andlogowillNOTbeshown
during POST.
[EFIDriver] EdriverwillstillbeinstalledwithEFIOS.
USB Support [Full Intial]
[Disabled] AllUSBdeviceswillNOTbeavailableuntilafterOSboot.
[PartialInitial] USBMassStorageandspecicUSBport/devicewillNOTbe
available before OS boot.
[FullInitial] AllUSBdeviceswillbeavailableinOSandPOST.
PS2 Devices Support [Enabled]
Ifthisoptionisdisabled,PS2deviceswillbeskipped.
Congurationoptions:[Disabled][Enabled]

Asus P11C-M/4L Specifications

General

ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2400, 2666 MHz
Processor socket	LGA 1151 (Socket H4)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Pentium, Intel Xeon
USB 2.0 connectors	1
Number of SATA III connectors	6
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Component for	PC
Motherboard chipset	Intel C242
Audio output channels	- channels
Motherboard form factor	micro ATX
BIOS type	-
Graphics card	AST2500
Storage temperature (T-T)	10 - 35 °C
Operating temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	20 - 90 %
LAN controller	Intel® I210-AT
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	244 mm
