Asus P3 Series Installation Manual

2 Installation manual
English
Front/Rear panel features
1. Optical drive eject button ( )
2. Optical drive bay cover
3. Power LED (
)
4. HDD LED (
)
5. Power button ( )
6. Front panel cover
7. Open the front panel cover (
)
8. Memory Stick
®
/Pro™card slot (MS)
9. Card reader LED (
R/W)
10. CompactFlash
®
card slot (CF)
11. SmartMedia
®
card slot (SM)
12. Secure Digital™/MultimediaCard
slot (SD/MMC)
13.* • 4-pin IEEE 1394a port (
)
• USB 2.0 ports (
)
• Headphones jack (
)
• Microphone jack (
)
Front (Close)
Front (Open)
Rear
16
15
'9;9(GXKHUTK
1
2
3
4
5
6
7
8
10
9
13
12
11
14
39
93
8=
9*33)
),
17
18
14.* • PS/2 keyboard port ( )
• PS/2 mouse port (
)
• Serial (COM) port (
)
• E-SATA port (
)
• Parallel port (
)
• VGA port (
)
• HDMI port (
)
• DVI-D port (
)
• Optical S/PDIF Out port (
)
• Coaxial S/PDIF Out port (
)
• 6-pin IEEE 1394a port (
)
• USB 2.0 ports (
)
• LAN (RJ-45) port (
)
• One of the following audio
jacks congurations:
• 6-channel • 8-channel

Asus P3 Series Specifications

General

Series	P3 Series
Category	Desktop
Audio	High Definition Audio
Processor	Intel Core i7/i5/i3
Memory	Up to 32GB DDR4
Storage	128GB SSD
Networking	Gigabit Ethernet
Expansion Slots	1 x PCIe x16, 2 x PCIe x1
Ports	USB 3.0, USB 2.0, HDMI, VGA, Audio Jack
Operating System	Windows 10 Pro
