ASUS P5E-VM HDMI 4-23
Memory Remap Feature [Enabled]
Allows you to enabled or disable the remapping of the overlapped PCI
memory above the total physical memory. Enable this option only when you
install 64-bit operating system. Conguration options: [Disabled] [Enabled]
Initiate Graphic Adapter [PEG/PCI]
Allows you to decide which graphics controller to use as the primary boot
device. Conguration options: [IGD] [PCI/IGD] [PCI/PEG] [PEG/IGD]
[PEG/PCI]
Internal Graphics Mode Select [Enabled, 8MB]
Allows you to decide whether to use the internal graphics device and select
the amount of memory used by the device.
Conguration options: [Disabled] [Enabled, 1MB] [Enabled, 8MB]
Set this item to [Disabled] if you intend to install a PCIE x16 graphics card to the
PCIE x16 slot.
PEG Port Control [Auto]
Conguration options: [Auto] [Disabled]
PEG Force x1 [Disabled]
This item appears when the PEG Port Control item is set to [Auto].
Conguration options: [Enabled] [Disabled]
The following item appears when the Internal Graphics Mode Select item is
set to [Enabled, 1MB] or [Enabled, 8MB].
Video Function Configuration
Video Function Conguration
DVMT Mode Select [DVMT Mode]
DVMT/FIXED Memory [256MB]
BIOS SETUP UTILITY
Advanced
Options
Fixed Mode
DVMT Mode
DVMT Mode Select [DVMT Mode]
Conguration options: [Fixed Mode] [DVMT Mode]
DVMT/FIXED Memory [256MB]
Conguration options: [128MB] [256MB]

Asus P5E-VM - Motherboard - Micro ATX Specifications

General

Form Factor	Micro ATX
Chipset	Intel G35
Socket	LGA 775
Memory Type	DDR2
Memory Slots	4
Maximum Memory	8 GB
PCI Express x16 Slots	1
PCI Express x1 Slots	1
PCI Slots	2
IDE Ports	1
USB Ports	12
Integrated Graphics	Intel GMA X3500
Audio Codec	ADI AD1988B
Audio Output	7.1 channel
LAN Controller	Marvell 88E8056
Network Interface	Gigabit Ethernet
Supported RAM Speed	800 MHz
SATA Ports	4
Video Outputs	VGA
