Asus P5G41C-M LX User Manual

x
P5G41C-M LX specications summary
* Specications are subject to change without notice.
ASUS exclusive
overclocking
features
SFS (Stepless Frequency Selection):
- FSB tuning from 200MHz to 800MHz at 1MHz increment
Overclocking Protection:
- ASUS C.P.R. (CPU Parameter Recall)
ASUS unique
features
ASUS CrashFree BIOS 3
ASUS AI NET 2
ASUS Q-Fan
ASUS EZ Flash 2
ASUS MyLogo 2
ASUS Anti-Surge Protection
ASUS Turbo Key
ASUS Express Gate
ASUS EPU-L
Back panel I/O ports 1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x LPT port
1 x COM port
1 x VGA port
1 x LAN (RJ-45) port
4 x USB 2.0/1.1 ports
3 x audio jacks
Internal connectors 2 x USB 2.0/1.1 connectors support additional
4 USB 2.0/1.1 ports
1 x IDE connector
4 x Serial ATA connectors
1 x Front panel audio connector
1 x System panel connector
1 x S/PDIF Out connector
1 x Internal speaker connector
1 x CPU fan connector
1 x Chassis fan connector
1 x 24-pin EATX power connector
1 x 4-pin ATX 12V power connector
BIOS 8Mb Flash ROM, AMI BIOS, PnP, DMI 2.0, WfM 2.0, ACPI 2.0a,
SM BIOS 2.5
Manageability WOL, PXE, WOR by Ring, PME Wake up
Accessories 1 x Ultra DMA 133/100/66 cable
2 x Serial ATA cables
1 x I/O shield
1 x User Manual
Support DVD Drivers
ASUS PC Probe II
ASUS Update
Anti-Virus software (OEM version)
Form factor uATX form factor: 9.6 in x 8.5 in (24.4 cm x 21.6 cm)

Asus P5G41C-M LX Specifications

General

Form Factor	Micro ATX
Chipset	Intel G41
CPU Socket	LGA 775
Memory Type	DDR3 / DDR2
Memory Slots	2
Maximum Memory	8 GB
Expansion Slots	1 x PCIe x16, 2 x PCIe x1, 1 x PCI
Storage Interface	4 x SATA 3Gb/s
Integrated Graphics	Intel GMA X4500
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
Video Outputs	1 x VGA
LAN	Realtek Gigabit LAN
USB Ports	8 x USB 2.0 (4 at back panel, 4 at mid-board)
