2-12 Chapter 2: BIOS information
2.4.3 Chipset
The Chipset menu allows you to change the advanced chipset settings. Select an item then
press <Enter> to display the sub-menu.
North Bridge Conguration
Memory Remap Feature [Enabled]
Allows you to enable or disable the remapping of overlapped PCI memory above the total
physical memory. Conguration options: [Disabled] [Enabled]
Congure DRAM Timing by SPD [Enabled]
Allows you to enable or disable congurating DRAM Timing by SPD.
Conguration options: [Enabled] [Disabled]
Initiate Graphic Adapter [PEG/PCI]
Allows you to select the graphics controller as the primary boot device.
Conguration options: [IGD] [PCI/IGD] [PCI/PEG] [PEG/IGD] [PEG/PCI]
IGD Graphics Mode Select [Enabled, 32MB]
Allows you to select the amout of system memory used by the Interanal graphics device.
Conguration options: [Disabled] [Enabled, 32MB] [Enabled, 48MB] [Enabled, 64MB]
[Enabled, 128MB]
GTT Graphics Memory Size [No VT mode, 2MB]
This item is not user- congurable.
The following item appears only when you installed an Intel
®
Pentium
®
4 or later CPU that
supports the Enhanced Intel SpeedStep
®
Technology (EIST).
Intel(R) SpeedStep(TM) Tech [Enabled]
Allows you to use the Enhanced Intel
®
SpeedStep
®
Technology. When set to [Enabled], you
can adjust the system power settings in the operating system to use the EIST feature. Set this
item to [Disabled] if you do not want to use the EIST.
Conguration options: [Enabled] [Disabled]
CPU TM Function [Enabled]
Enables or disables Intel
®
CPU Thermal Monitor (TM) function, a CPU overheating protection
function. When enabled, the CPU core frequency and voltage are reduced when the CPU
overheats. Conguration options: [Disabled] [Enabled]
Execute-Disable Bit Capability [Enabled]
Allows you to enable or disable the No-Execution Page Protection Technology. Setting this
item to [Disabled] forces the XD feature ag to always return to zero (0).
Conguration options: [Disabled] [Enabled]
