4-18 Chapter 4: BIOS setup
The following items appear when you set the DRAM Timing Control item to
[Manual].
CAS# Latency [ 5]
Conguration options: [3] [4] [5] [6]
RAS# to CAS# Delay [ 5 DRAM Clocks]
Conguration options: [3 DRAM Clocks] [4 DRAM Clocks]~[9 DRAM Clocks]
[10 DRAM Clocks]
RAS# Precharge [ 5 DRAM Clocks]
Conguration options: [3 DRAM Clocks] [4 DRAM Clocks]~[9 DRAM Clocks]
[10 DRAM Clocks]
RAS# Activate to Precharge [9 DRAM Clocks]
Conguration options: [3 DRAM Clocks] [4 DRAM Clocks]~[17 DRAM Clocks]
[18 DRAM Clocks]
TWR [Auto]
Conguration options: [Auto] [ 1 DRAM Clocks]~[15 DRAM Clocks]
TRFC [Auto]
Conguration options: [Auto] [20 DRAM Clocks] [25 DRAM Clocks]
[30 DRAM Clocks] [35 DRAM Clocks] [42 DRAM Clocks]
TWTR [Auto]
Conguration options: [Auto] [ 1 DRAM Clocks]~[15 DRAM Clocks]
TRRD [Auto]
Conguration options: [Auto] [ 1 DRAM Clocks]~[15 DRAM Clocks]
TRTP [Auto]
Conguration options: [Auto] [ 1 DRAM Clocks]~[15 DRAM Clocks]
DRAM Static Read Control [Auto]
Conguration options: [Auto] [Disabled] [Enabled]
Transaction Booster [Auto]
Conguration options: [Auto] [Disabled] [Enabled]
Clock Over-Charging Mode [Auto]
Conguration options: [Auto] [700mV] [800mV] [900mV] [1000mV]
CPU Spread Spectrum [Auto]
Allows you to enable or disable the CPU spread spectrum.
Conguration options: [Auto] [Disabled]
PCIE Spread Spectrum [Auto]
Allows you to enable or disable the PCIE spread spectrum.
Conguration options: [Auto] [Disabled]
