ASUS P5K-VM 1-39
Q-Connector (system panel)
You can use ASUS Q-Connector to connect / disconnect chassis front panel
cables by only a few steps. Directions below shows how to install ASUS Q-
Connector.
Step2.
Properly install the ASUS Q-Connector to the
System panel connctor.
Step1.
Connect correct front panel to ASUS Q-
Connector rst. You can refer to the marking
on Q-Connector itself to know the detail pin
denition.
Step3.
Front panel functions are enabled.
