Asus P5N32-E SLI Plus - Page 30

2-6
第二章：硬體裝置資訊
內部連接插槽 頁數
1. Floppy disk drive connector (34-1 pin FLOPPY) 2-26
2. IDE connector (40-1 pin PRI_IDE)
2-26
3. Serial ATA connectors (7-pin SATA1-6)
2-27
4. USB connectors (10-1 pin USB56, USB78, USB910)
2-28
5. IEEE 1394a port connector (10-1 pin IE1394_2)
2-29
6. CPU, chassis, and power fan connectors (4-pin CPU_FAN, 3-
pin CHA_FAN1, 3-pin OPT-FAN1~5, 3-pin PWR_FAN)
2-30
7. Chassis intrusion connector (4-1 pin CHASSIS)
2-31
8. ATX power connectors (24-pin EATXPWR, 2x4-pin ATX12V)
2-31
9. S/PDIF output connector (4-1 pin SPDIF_02)
2-33
10. System panel connector (20-8-pin PANEL)
•System power LED (2-pin PLED)
•Hard disk drive activity LED (2-pin IDE_LED)
•System warning speaker (4-pin SPEAKER)
•ATX power button/soft-off button (2-pin PWRSW)
•Reset button (2-pin RESET)
2-34
11. ASUS Q-connector (system panel)
2-35
