xi
P5Q3
specications summary
CPU LGA775 socket for Intel® Core™2 Extreme/Core™2
Quad/ Core™2 Duo/Pentium® dual-core/Celeron® dual-
core /Celeron® Processors
Compatible with Intel® 05B/05A/06 processors
Support Intel® 45nm Multi-Core CPU
* This motherboard isdesigned with VRD11.1 power
phase, and cannot be compatible with VRD10 designed
CPU. Please refer to www.asus.com for “CPU support
list”.
* Refer to www.asus.com for Intel CPU support list
Chipset Intel
®
P45 / ICH10R
System Bus 1600 / 1333 / 1066 / 800 MHz
Memory 4 x DIMM, max. 16GB, DDR3 1800 (O.C) / 1600 / 1333 /
1066 MHz, non-ECC, un-buffered memory
Dual channel memory architecture
* DDR3 1600 MHz or above DIMMs work only on the
Orange slots for one DIMM per channel.
* When installing total memory of 4GB capacity or more,
Windows® 32-bit operation system may only recognize
less than 3GB. Hence, a total installed memory of less
than 3GB is recomended.
* Please Refer to www.asus.com for the Memory QVL
(Qualied Vendors Lists).
Expansion Slots 2 x PCIe 2.0 x16, support ATI CrossFireX™ technology
dual at x 8 link (PCIe x16_1 blue, PCIe x16_2 black*)
3 x PCIe x1
2 x PCI
* PCIE x16 slot (black at max. x8 link)
Storage Intel
®
ICH10R Southbridge
- 6 x SATA 3Gb/s ports
- Intel
®
Matrix Storage, supporting SATA RAID 0,1, 5
and 10
JMicron
®
JMB363 SATA&PATA controllers
- 1 x UltraDMA 133/100/66 for up to 2 PATA devices
- 1 x External SATA 3Gb/s port (SATA On-the-Go)
JMicron
®
JMB322 (Drive Xpert Technology)
- 2 x SATA 3Gb/s ports
- Supports EZ Backup and Super Speed functions
LAN Realtek
®
8111C PCIe Gb LAN controller, featuring AI
NET2
Audio Realtek
®
ALC1200 8-channel High Denition Audio
CODEC
- Supports Jack-detection, Multi-streaming, Front
Panel Jack-Retasking technology
- Coaxial/Optical S/PDIF out ports at back I/O
- ASUS Noise Filter
(continued on the next page)
