P5QC specications summary
CPU
LGA775 socket for Intel
®
Core™2 Extreme /
Core™2 Quad /Core™2 Duo / Pentium
®
dual-core /
Celeron
®
dual-core / Celeron
®
Processors
Compatible with Intel
®
05B/05A/06 processors
Intel
®
45nm Multi-Core CPU support
* Refer to www.asus.com for Intel CPU support list
Chipset Intel
®
P45 / ICH10R with Intel
®
Fast Memory Access
Technology
System Bus 1600 / 1333 / 1066 / 800 MHz
Memory
2 x DIMM, max. 8GB, DDR3 1333 / 1066 / 800 MHz,
non-ECC, un-buffered memory
4 x DIMM, max. 16GB, DDR2 1066 / 800 / 667 MHz,
non-ECC, un-buffered memory
Dual channel memory architecture
* DDR2 1066MHz DIMMs work only on the black slots for
one DIMM per channel. Ensure to install the DDR2
1066MHz DIMMs ONLY on the BLACK slots!
* Refer to www.asus.com or this user manual for the
Memory QVL (Qualied Vendors Lists).
Expansion Slots
1 x PCIe 2.0 x16 slot supports PCIe 2.0 mode
3 x PCIe x1 slots
2 x PCI slots
Storage Intel
®
ICH10R Southbridge:
- 6 x SATA 3.0 Gb/s ports
- Intel
®
Matrix Storage supporting SATA RAID 0,1,
5, and 10 and Mix Mode (Intel matrix storage tech.)
Marvell 88SE6111 controller:
- 1 x Ultra DMA 133/100/66 for up to 2 PATA devices
- 1 x SATA 3.0 Gb/s for Drive Xpert
Silicon Image SIL5723 controller (Drive Xpert
Technology):
- 2 x SATA 3.0 Gb/s ports
- Supports RAID 0 and RAID 1
LAN
PCIe Gigabit LAN controller, featuring AI NET2
Audio
Realtek
®
ALC1200, 8-channel High Denition Audio
CODEC
- Supports Jack-Detecting, Multi-streaming, and Front
Panel Jack-Retasking
- Coaxial S/PDIF out ports at back I/O
- ASUS Noise-Filtering
IEEE 1394
LSI
®
L-FW3227 1394a controller supports 2 x IEEE
1394a ports (one at mid-board, one at back panel)
USB
12 x USB 2.0 ports (6 ports at mid-board, 6 ports at back
panel)
(continued on the next page)
