Asus P5RD1-VM User Manual

1-321-32
1-321-32
1-32
Chapter 1: Product introductionChapter 1: Product introduction
Chapter 1: Product introductionChapter 1: Product introduction
Chapter 1: Product introduction
8.8.
8.8.
8.
USB connectors (10-1 pin USB56, USB78)USB connectors (10-1 pin USB56, USB78)
USB connectors (10-1 pin USB56, USB78)USB connectors (10-1 pin USB56, USB78)
USB connectors (10-1 pin USB56, USB78)
These connectors are for USB 2.0 ports. Connect the optional
USB module cable to any of these connectors, then install the module
to a slot opening at the back of the system chassis. These USB
connectors comply with USB 2.0 specification that supports up to
480 Mbps connection speed.
®
P5RD1-VM
P5RD1-VM USB 2.0 connectors
USB56
USB+5V USB_P6- USB_P6+ GND NC
USB+5V
USB_P5-
USB_P5+
GND
1
USB78
USB+5V USB_P8- USB_P8+ GND NC
USB+5V
USB_P7-
USB_P7+
GND
1
9.9.
9.9.
9.
Internal audio connectors (4-pin CD [black], 4-pin AUXInternal audio connectors (4-pin CD [black], 4-pin AUX
Internal audio connectors (4-pin CD [black], 4-pin AUXInternal audio connectors (4-pin CD [black], 4-pin AUX
Internal audio connectors (4-pin CD [black], 4-pin AUX
[white])[white])
[white])[white])
[white])
These connectors allow you to receive stereo audio input from sound
sources such as a CD-ROM, TV tuner, or MPEG card.
®
P5RD1-VM
P5RD1-VM Internal audio connectors
Right Audio Channel
Left Audio Channel
Ground Ground
AUX
(White)
CD
(Black)
Right Audio Channel
Left Audio Channel
Ground Ground
