Asus P8H61-I LX R2.0 User Manual

1-11Chapter 1: Product introduction
DDR3-2400 MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket support (Optional)
1 DIMM 2 DIMMs
CORSAIR CMGTX8(XMP) 8GB (2GBx 4) SS - - 10-12-10-27 1.65V • •
G.SKILL
F3-19200CL11Q-
16GBZHD(XMP1.3)
16GB (4 x4GB) DS - - 11-11-11-31 1.65V • •
G.SKILL
F3-19200CL9D-
4GBPIS(XMP)
4GB(2x 2GB) DS - - 9-11-9-28 1.65V • •
GEIL GET34GB2400C9DC(XMP) 2GB DS - - 9-11-9-27 1.65V • •
KINGMAX
FLLE88F-C8KKAA
HAIS(XMP)
2GB SS - - 10-11-10-30 1.8V • •
Transcend
TX2400KLU-
4GK(427652)(XMP)
4GB(2 x 2GB) SS - - - 1.65V • •
Transcend
TX2400KLU-4GK
(381850)(XMP)
4GB(2x 2GB) SS - - 9 1.65V • •
Transcend
TX2400KLU-
4GK(374243)(XMP)
4GB(2x 2GB) DS - - 9 1.65V • •
PATRIOT PVV34G2400C9K(XMP) 4GB(2x 2GB) DS - - 9-11-9-27 1.65V • •
DDR3-2250 MHz capability
Vendors Part No. Size SS/DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs
KINGSTON KHX2250C9D3T1K2/4GX(XMP) 4GB (2x 2GB) DS - - - 1.65V • •
DDR3-2200 MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket support (Optional)
1 DIMM 2 DIMMs
GEIL GET34GB2200C9DC(XMP) 2GB DS - - 9-10-9-28 1.65V • •
GEIL GET38GB2200C9ADC(XMP) 4GB DS - - 9-11-9-28 1.65V • •
KINGMAX FLKE85F-B8KJAA-FEIS(XMP) 2GB DS - - - - • •
KINGMAX FLKE85F-B8KHA EEIH(XMP) 4GB(2 x 2GB) DS - - - 1.5V-1.7V • •
KINGMAX FLKE85F-B8KJA FEIH(XMP) 4GB(2 x 2GB) DS - - - 1.5V-1.7V • •
DDR3-2133 MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs
A-DATA
AX3U2133GC2G9B-
DG2(XMP)
2GB SS - - 9-11-9-27 1.55~1.75V • •
CORSAIR
CMT16GX3M4X2133C9(XMP
1.3)
16GB (4GB x4) DS - - 9-11-10-27 1.50V • •
CORSAIR CMT4GX3M2A2133C9(XMP) 4GB(2x 2GB) DS - - 9-10-9-24 1.65V • •
CORSAIR CMT4GX3M2B2133C9(XMP) 4GB(2x 2GB) DS - - 9-10-9-27 1.50V • •
CORSAIR CMT8GX3M2B2133C9(XMP) 8GB (4GB x 2) DS - - 9-11-9-27 1.50V • •
G.SKILL
F3-17000CL9Q-
16GBZH(XMP1.3)
16GB (4GB x4) DS - - 9-11-10-28 1.65V • •
GEIL GE34GB2133C9DC(XMP) 2GB DS - - 9-9-9-28 1.65V • •
GEIL GU34GB2133C9DC(XMP) 4GB(2 x 2GB) DS - - 9-9-9-28 1.65V • •
KINGSTON
KHX2133C11D3T1K2/
16GX(XMP)
16GB(8GB x 2) DS - - - 1.6V • •
KINGSTON
KHX2133C9AD3T1K2/
4GX(XMP)
4GB (2x 2GB) DS - - - 1.65V • •
KINGSTON
KHX2133C9AD3X2K2/
4GX(XMP)
4GB(2 x 2GB) DS - - 9-11-9-27 1.65V • •
KINGSTON
KHX2133C9AD3T1K4/
8GX(XMP)
8GB(4 x 2GB) DS - - 9-11-9-27 1.65V • •
KINGSTON
KHX2133C9AD3T1FK4/
8GX(XMP)
8GB(4x 2GB) DS - - - 1.65V • •
PATRIOT PGD38G2133C11K(XMP) 16GB (4GB x4) DS - - 11-11-11-30 1.65V • •

Asus P8H61-I LX R2.0 Specifications

General

Form Factor	Mini ITX
Chipset	Intel H61
CPU Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
PCIe x16 Slots	1
SATA Ports	4 x SATA 3Gb/s
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
Video Outputs	1 x DVI, 1 x HDMI
LAN	Realtek 8111E Gigabit LAN Controller
USB Ports	8 x USB 2.0
