Asus P8H61-I LX R2.0 User Manual

1-13Chapter 1: Product introduction
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket
support (Optional)
1 DIMM 2 DIMMs
G.SKILL F3-12800CL7D-4GBECO(XMP) 4GB(2 x 2GB) DS - - 7-7-8-24 XMP 1.35V • •
G.SKILL F3-12800CL7D-4GBRM(XMP) 4GB(2 x 2GB) DS - - 7-8-7-24 1.6V • •
G.SKILL F3-12800CL8D-4GBRM(XMP) 4GB(2 x 2GB) DS - - 8-8-8-24 1.60V • •
G.SKILL F3-12800CL9D-4GBECO(XMP) 4GB(2 x 2GB) DS - - 9-9-9-24 XMP 1.35V • •
G.SKILL F3-12800CL9D-4GBRL(XMP) 4GB(2 x 2GB) DS - - 9-9-9-24 1.5V • •
G.SKILL F3-12800CL9T-6GBNQ(XMP) 6GB(3 x 2GB) DS - - 9-9-9-24 1.5V~1.6V • •
G.SKILL F3-12800CL7D-8GBRH(XMP) 8GB(2 x 4GB) DS - - 7-8-7-24 1.6V • •
G.SKILL F3-12800CL8D-8GBECO(XMP) 8GB(2 x 4GB) DS - - 8-8-8-24 XMP 1.35V • •
G.SKILL F3-12800CL9D-8GBRL(XMP) 8GB(2 x 4GB) DS - - 9-9-9-24 1.5V • •
GEIL GET316GB1600C9QC(XMP) 16GB (4x 4GB) DS - - 9-9-9-28 1.6V • •
GEIL GV34GB1600C8DC(XMP) 2GB DS - - 8-8-8-28 1.6V • •
HYNIX HMT351U6CFR8C-PB 4GB DS HYNIX
H5TQ2G83
CFR PBC
- - • •
KINGMAX FLGD45F-B8MF7 MAEH(XMP) 1GB SS - - 7 - • •
KINGMAX FLGE85F-B8KJ9A FEIS(XMP) 2GB DS - - - - • •
KINGMAX FLGE85F-B8MF7 MEEH(XMP) 2GB DS - - 7 - • •
KINGSTON KHX1600C9D3P1K2/4G 4GB(2 x 2GB) SS - - - 1.5V • •
KINGSTON KHX1600C9D3K3/12GX(XMP) 12GB(3x4GB) DS - - 9-9-9-27 1.65V • •
KINGSTON
KHX1600C9D3T1BK3/
12GX(XMP)
12GB(3x4GB) DS - - 9-9-9-27 1.65V • •
KINGSTON KHX1600C9D3K4/16GX(XMP) 16GB (4GB x4) DS - - - 1.65V • •
KINGSTON KHX1600C9AD3/2G 2GB DS - - - 1.65V • •
KINGSTON KVR1600D3N11/2G-ES 2GB DS KTC
D1288JPN
DPLD9U
11-11-11-28 1.35V-1.5V • •
KINGSTON KHX1600C7D3K2/4GX(XMP) 4GB (2x 2GB) DS - - - 1.65V • •
KINGSTON KHX1600C8D3K2/4GX(XMP) 4GB(2 x 2GB) DS - - 8 1.65V • •
KINGSTON KHX1600C8D3T1K2/4GX(XMP) 4GB(2 x 2GB) DS - - 8 1.65V • •
KINGSTON KHX1600C9D3K2/4GX(XMP) 4GB(2 x 2GB) DS - - 9 1.65V • •
KINGSTON KHX1600C9D3LK2/4GX(XMP) 4GB(2 x 2GB) DS - - 9 XMP 1.35V • •
KINGSTON KHX1600C9D3X2K2/4GX(XMP) 4GB(2 x 2GB) DS - - 9-9-9-27 1.65V • •
KINGSTON KHX1600C9D3T1K3/6GX(XMP) 6GB (3x 2GB) DS - - - 1.65V • •
KINGSTON KHX1600C9D3K3/6GX(XMP) 6GB(3 x 2GB) DS - - 9 1.65V • •
KINGSTON KHX1600C9D3T1BK3/6GX(XMP) 6GB(3 x 2GB) DS - - 9-9-9-27 1.65V • •
KINGSTON KHX1600C9D3K2/8GX(XMP) 8GB(2 x 4GB) DS - - 9-9-9-27 1.65V • •
KINGSTON KHX1600C9D3P1K2/8G 8GB(2 x 4GB) DS - - - 1.5V • •
Super Talent WA160UX6G9 6GB(3 x 2GB) DS - - 9 - • •
Transcend JM1600KLN-8GK 8GB(4GBx2) DS Transcend TK483PCW3 - - • •
AMD AE32G1609U1-U 2GB SS -
23EY4587M
B6H11503M
9-9-9-24 1.5V • •
AMD AE34G1609U2-U 4GB DS AMD
23EY4587M
B6H11503M
9-9-9-24 1.5V
ASint SLZ302G08-EGN1C 2GB SS Asint
SLZ302G0
8-GN1C
- - • •
Asint SLZ3128M8-EGJ1D(XMP) 2GB DS Asint 3128M8-GJ1D 9-9-9-24 1.6V • •
Asint SLA302G08-EGG1C(XMP) 4GB DS Asint 302G08-GG1C - - • •
Asint SLA302G08-EGJ1C(XMP) 4GB DS Asint 302G08-GJ1C - - • •
ASint SLA302G08-EGN1C 4GB DS Asint
SLA302G
08-GN1C
- - • •
ASint SLB304G08-EGN1B 8GB DS Asint
SLB304G
08-GN1B
- - • •
Elixir M2P2G64CB8HC9N-DG(XMP) 2GB DS - - - - • •
Mushkin 998659(XMP) 6GB(3 x 2GB) DS - - 9-9-9-24 - • •
Mushkin 998659(XMP) 6GB(3 x 2GB) DS - - 9-9-9-24 1.5~1.6V • •
PATRIOT PGD316G1600ELK(XMP) 32GB(8GBx4) DS - - 9-9-9-24 1.65V • •
PATRIOT PGS34G1600LLKA 4GB(2 x 2GB) DS - - 7-7-7-20 1.7V • •
SanMax SMD-4G68HP-16KZ 4GB DS HYNIX
H5TQ2G83
BFR PBC
- - • •
Silicon
Power
SP002GBLTU160V02(XMP) 2GB SS S-POWER 20YT5NG-1201 - - • •
Silicon
Power
SP004GBLTU160V02(XMP) 4GB DS S-POWER 20YT5NG-1201 - - • •
SS: Single-sided / DS: Double-sided
DIMM support:
• 1 DIMM*: Supports one module inserted into either slot as single-channel memory
conguration.
• 2 DIMMs*: Supports one pair of modules inserted into both slots as one pair of dual-
channel memory conguration.
Visit the ASUS website at www.asus.com for the latest QVL.

Asus P8H61-I LX R2.0 Specifications

General

Form Factor	Mini ITX
Chipset	Intel H61
CPU Socket	LGA 1155
Memory Slots	2
Memory Type	DDR3
Maximum Memory	16 GB
PCIe x16 Slots	1
SATA Ports	4 x SATA 3Gb/s
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
Video Outputs	1 x DVI, 1 x HDMI
LAN	Realtek 8111E Gigabit LAN Controller
USB Ports	8 x USB 2.0
