Asus P8H61-M LX PLUS R2.0 User Manual

1-1Chapter 1: Product introduction
Chapter 1
Product introduction
If any of the above items is damaged or missing, contact your retailer.
1.3 Special features
1.3.1 Product highlights
Intel® LGA1155 Intel® Second Generation Core™ i7 / Core™
i5 / Core™ i3 processors
This motherboard supports the Intel® second generation Core™ i7 /
Core™ i5 / Core™ i3 processors in LGA1155 package with memory and
PCI Express controllers integrated to support 2-channel (2 DIMMs) DDR3
memory and 16 PCI Express 2.0 lanes. This provides great graphics
performance. Intel® second generation Core™ i7 / Core™ i5 / Core™ i3
processors are among the most powerful and energy efcient CPUs in
the world.
1.1 Welcome!
Thank you for buying an ASUS
®
P8H61-M LX R2.0 Series motherboard!
The motherboard delivers a host of new features and the latest technologies, making it
another standout in the long line of ASUS quality motherboards!
Before you start installing the motherboard and adding components, check the items in your
package with the list below.
1.2 Package contents
Check your motherboard package for the following items.
Motherboard ASUS P8H61-M LX 2.0 Series motherboard
Cables 2 x Serial ATA 3.0Gb/s cables
Accessories 1 x I/O shield
Application DVD ASUS motherboard support DVD
Documentation User Manual

Asus P8H61-M LX PLUS R2.0 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
Number of SATA II connectors	4
Number of Parallel ATA connectors	-
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA II
Maximum resolution	2048 x 1536 pixels
PCI Express x1 slots	3
PCI Express slots version	2.0, 3.0
Networking features	Gigabit Ethernet
BIOS type	AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	183 mm
Width	244 mm
