Asus P8H61-M LX2 R2.0 User Manual

ASUS P8H61-M LX2 R2.0 1-14
Vendor Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket
support
(Optional)
1DIMM 2DIMMs
KINGSTON KHX1600C9D3P1K2/4G
4GB(2 x
2GB)
SS - - - 1.5V
KINGSTON KHX1600C9D3K3/12GX(XMP)
12GB
(3x4GB)
DS - - 9-9-9-27 1.65V
KINGSTON
KHX1600C9D3T1BK3/
12GX(XMP)
12GB
(3x4GB)
DS - - 9-9-9-27 1.65V
KINGSTON KHX1600C9D3K4/16GX(XMP)
16GB (
4GB x4 )
DS - - - 1.65V
KINGSTON KHX1600C9AD3/2G 2GB DS - - - 1.65V
KINGSTON KVR1600D3N11/2G-ES 2GB DS KTC D1288JPNDPLD9U 11-11-11-28 1.35V-1.5V
KINGSTON KHX1600C7D3K2/4GX(XMP)
4GB ( 2x
2GB )
DS - - - 1.65V
KINGSTON KHX1600C8D3K2/4GX(XMP)
4GB(2 x
2GB)
DS - - 8 1.65V
KINGSTON KHX1600C8D3T1K2/4GX(XMP)
4GB(2 x
2GB)
DS - - 8 1.65V
KINGSTON KHX1600C9D3K2/4GX(XMP)
4GB(2 x
2GB)
DS - - 9 1.65V
KINGSTON KHX1600C9D3LK2/4GX(XMP)
4GB(2 x
2GB)
DS - - 9 XMP 1.35V
KINGSTON KHX1600C9D3X2K2/4GX(XMP)
4GB(2 x
2GB)
DS - - 9-9-9-27 1.65V
KINGSTON KHX1600C9D3T1K3/6GX(XMP)
6GB ( 3x
2GB )
DS - - - 1.65V
KINGSTON KHX1600C9D3K3/6GX(XMP)
6GB(3 x
2GB)
DS - - 9 1.65V
KINGSTON
KHX1600C9D3T1BK3/
6GX(XMP)
6GB(3 x
2GB)
DS - - 9-9-9-27 1.65V
KINGSTON KHX1600C9D3K2/8GX(XMP)
8GB(2 x
4GB)
DS - - 9-9-9-27 1.65V
KINGSTON KHX1600C9D3P1K2/8G
8GB(2 x
4GB)
DS - - - 1.5V
Super Talent WA160UX6G9
6GB(3 x
2GB)
DS - - 9 -
Transcend JM1600KLN-8GK
8GB
(4GBx2)
DS Transcend TK483PCW3 - -
AMD AE32G1609U1-U 2GB SS - 23EY4587MB6H11503M 9-9-9-24 1.5V
AMD AE34G1609U2-U 4GB DS AMD 23EY4587MB6H11503M 9-9-9-24 1.5V
Asint SLZ3128M8-EGJ1D(XMP) 2GB DS Asint 3128M8-GJ1D 9-9-9-24 1.6V
Asint SLA302G08-EGG1C(XMP) 4GB DS Asint 302G08-GG1C - -
Asint SLA302G08-EGJ1C(XMP) 4GB DS Asint 302G08-GJ1C - -
Elixir M2P2G64CB8HC9N-DG(XMP) 2GB DS - - - -
Mushkin 998659(XMP)
6GB (3 x
2GB)
DS - - 9-9-9-24 -
Mushkin 998659(XMP)
6GB (3 x
2GB)
DS - - 9-9-9-24 1.5~1.6V
PATRIOT PGD316G1600ELK(XMP)
32GB
(8GBx4)
DS - - 9-9-9-24 1.65V
PATRIOT PGS34G1600LLKA
4GB (2 x
2GB)
DS - - 7-7-7-20 1.7V
SanMax SMD-4G68HP-16KZ 4GB DS HYNIX H5TQ2G83BFR PBC - -
Silicon
Power
SP002GBLTU160V02(XMP) 2GB SS S-POWER 20YT5NG-1201 - -
Silicon
Power
SP004GBLTU160V02(XMP) 4GB DS S-POWER 20YT5NG-1201 - -
DDR3-1600 MHz capability

Asus P8H61-M LX2 R2.0 Specifications

General

Non-ECC	Yes
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2000, 2133, 2200 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
USB 2.0 connectors	4
Number of EATX power connectors	1
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	6
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA II
Parallel processing technology support	-
Cables included	SATA
LAN controller	Realtek RTL8111F
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	198.2 mm
Width	244 mm
