Asus P8H61-M LX2 R2.0 User Manual

ASUS P8H61-M LX2 R2.0 1-16
DDR3-2200 MHz capability
Vendors Part No. Size SS/DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket
support
(optional)
1DIMM 2DIMMs
G.SKILL
F3-17600CL8D-
4GBPS(XMP)
4GB(2 x
2GB)
DS - - 8-8-8-24 1.65V
GEIL GET34GB2200C9DC (XMP) 2GB DS - - 9-10-9-28 1.65V
GEIL
GET38GB2200C9ADC
(XMP)
4GB DS - - 9-11-9-28 1.65V
KINGMAX
FLKE85F-B8KJAA-
FEIS(XMP)
2GB DS - - - -
KINGMAX
FLKE85F-B8KHA
EEIH(XMP)
4GB (2 x
2GB)
DS - - - 1.5V-1.7V
KINGMAX
FLKE85F-B8KJA
FEIH(XMP)
4GB (2
x2GB)
DS - - - 1.5V-1.7V
DDR3-2250 MHz capability
Vendors Part No. Size SS/DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket
support
(optional)
1DIMM 2DIMMs
Kingston
KHX2250C9D3T1K2/
4GX(XMP)
4GB (2
x2GB)
DS - - - 1.65V
DDR3-2400 MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket
support (optional)
1DIMM 2DIMMs
CORSAIR CMGTX8(XMP) 8GB (2GBx 4) SS - - 10-12-10-27 1.65V
G.SKILL
F3-19200CL11Q-
16GBZHD(XMP1.3)
16GB ( 4GB x4 ) DS - - 11-11-11-31 1.65V
G.SKILL
F3-19200CL9D-
4GBPIS(XMP)
4GB(2x 2GB) DS - - 9-11-9-28 1.65V
GEIL GET34GB2400C9DC(XMP) 2GB DS - - 9-11-9-27 1.65V
KINGMAX
FLLE88F-C8KKAA
HAIS(XMP)
2GB SS - - 10-11-10-30 1.8V
Transcend
TX2400KLU-
4GK(427652)(XMP)
4GB(2 x 2GB) SS - - - 1.65V
Transcend
TX2400KLU-4GK
(381850)(XMP)
4GB(2x 2GB) SS - - 9 1.65V
Transcend
TX2400KLU-
4GK(374243)(XMP)
4GB(2x 2GB) DS - - 9 1.65V
PATRIOT PVV34G2400C9K(XMP) 4GB(2x 2GB) DS - - 9-11-9-27 1.65V

Asus P8H61-M LX2 R2.0 Specifications

General

Non-ECC	Yes
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 1866, 2000, 2133, 2200 MHz
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
USB 2.0 connectors	4
Number of EATX power connectors	1
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	6
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA II
Parallel processing technology support	-
Cables included	SATA
LAN controller	Realtek RTL8111F
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	198.2 mm
Width	244 mm
