P8H61-M PLUS2 specications summary
(continued on the next page)
CPU LGA1155 socket for Intel
®
Second Generation Core™ i7 / Core™
i5 / Core™ i3 processors
Supports 32nm CPU
Supports Enhanced Intel
®
SpeedStep Technology (EIST)
* Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
H61 Express Chipset
Memory 2 x DIMM, max. 16GB*, DDR3 1333 / 1066 MHz, non-ECC,
un-buffered memory
Dual-channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)
* The maximum 16GB memory capacity can be supported with
8GB or above DIMMs. ASUS will update the memory QVL once
the DIMMs are available in the market.
** Refer to www.asus.com for the latest Memory QVL (Qualied
Vendors List).
*** When you install a total memory of 4GB capacity or more,
Windows
®
32-bit operating system may only recognize less
than 3GB. We recommend a maximum of 3GB system memory
if you are using a Windows
®
32-bit operating system.
Expansion slots 1 x PCI Express 2.0 x16 slot
1 x PCI Express 2.0 x1 slot
1 x PCI slot
Storage
Intel
®
H61 Express Chipset:
- 4 x Serial ATA 3.0 Gb/s connectors
LAN
Realtek
®
8111E PCIe Gigabit LAN controller
Audio Realtek
®
ALC887 8-channel* High Denition Audio CODEC
* Use a chassis with HD audio module in the front panel to
support an 8-channel audio output.
USB Intel
®
H61 Express Chipset:
- 10 x USB 2.0/1.1 ports (4 ports at the mid-board, 6 ports at
the back panel)
ASUS unique
features
ASUS ESD Guards
GPU Boost
ASUS Anti-Surge Protection
ASUS Q-Fan 2
ASUS EFI BIOS
ASUS CrashFree BIOS 3
ASUS EZ Flash 2
ASUS MyLogo 2™

Asus P8H61-M PLUS2 Specifications

General

Form Factor	Micro ATX
Chipset	Intel H61
Socket	LGA 1155
Memory Slots	2 x DIMM
Maximum Memory	16 GB
Memory Type	DDR3
Storage Interface	4 x SATA 3Gb/s
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
LAN	Realtek 8111E , 1 x Gigabit LAN Controller(s)
RAID Support	No
Expansion Slots	2 x PCIe 2.0 x1
USB Ports	8 x USB 2.0
Video Outputs	1 x DVI
