Asus P8H61-MX R2.0 User Manual

ASUS P8H61-MX Series1-14
Vendors Part NO. Size SS/
DS
Chip
Brand
Chip NO. Timing Voltage DIMM socket
support (optional)
1DIMM 2DIMMs
G.SKILL F3-12800CL9D-2GBNQ(XMP) 2GB(2 x 1GB) SS - - 9-9-9-24 1.5V · ·
G.SKILL F3-12800CL7D-4GBRH(XMP) 4GB(2 x 2GB) SS - - 7-7-7-24 1.6V · ·
G.SKILL F3-12800CL7D-4GBECO(XMP) 4GB(2 x 2GB) DS - - 7-7-8-24 XMP
1.35V
· ·
G.SKILL F3-12800CL7D-4GBRM(XMP) 4GB(2 x 2GB) DS - - 7-8-7-24 1.6V · ·
G.SKILL F3-12800CL8D-4GBRM(XMP) 4GB(2 x 2GB) DS - - 8-8-8-24 1.60V ·
G.SKILL F3-12800CL9D-4GBECO(XMP) 4GB(2 x 2GB) DS - - 9-9-9-24 XMP
1.35V
· ·
G.SKILL F3-12800CL9D-4GBRL(XMP) 4GB(2 x 2GB) DS - - 9-9-9-24 1.5V · ·
G.SKILL F3-12800CL9T-6GBNQ(XMP) 6GB(3 x 2GB) DS - - 9-9-9-24 1.5V~1.6V · ·
G.SKILL F3-12800CL7D-8GBRH(XMP) 8GB(2 x 4GB) DS - - 7-8-7-24 1.6V · ·
G.SKILL F3-12800CL8D-8GBECO(XMP) 8GB(2 x 4GB) DS - - 8-8-8-24 XMP
1.35V
·
G.SKILL F3-12800CL9D-8GBRL(XMP) 8GB(2 x 4GB) DS - - 9-9-9-24 1.5V · ·
GEIL GET316GB1600C9QC(XMP) 16GB ( 4x
4GB )
DS - - 9-9-9-28 1.6V
GEIL GV34GB1600C8DC(XMP) 2GB DS - - 8-8-8-28 1.6V ·
HYNIX HMT351U6CFR8C-PB 4GB DS HYNIX H5TQ2G83CFR PBC - - ·
KINGMAX FLGD45F-B8MF7 MAEH(XMP) 1GB SS - - 7 - · ·
KINGMAX FLGE85F-B8KJ9A FEIS(XMP) 2GB DS - - - - · ·
KINGMAX FLGE85F-B8MF7 MEEH(XMP) 2GB DS - - 7 - · ·
KINGSTON KHX1600C9D3P1K2/4G 4GB(2 x 2GB) SS - - - 1.5V · ·
KINGSTON KHX1600C9D3K3/12GX(XMP) 12GB (3x4GB) DS - - 9-9-9-27 1.65V · ·
KINGSTON KHX1600C9D3T1BK3/12GX(XMP) 12GB (3x4GB) DS - - 9-9-9-27 1.65V · ·
KINGSTON KHX1600C9D3K4/16GX(XMP) 16GB ( 4GB
x4 )
DS - - - 1.65V · ·
KINGSTON KHX1600C9AD3/2G 2GB DS - - - 1.65V · ·
KINGSTON KVR1600D3N11/2G-ES 2GB DS KTC D1288JPNDPLD9U 11-11-11-28 1.35V-
1.5V
· ·
KINGSTON KHX1600C7D3K2/4GX(XMP) 4GB ( 2x 2GB ) DS - - - 1.65V · ·
KINGSTON KHX1600C8D3K2/4GX(XMP) 4GB (2 x 2GB) DS - - 8 1.65V · ·
KINGSTON KHX1600C8D3T1K2/4GX(XMP) 4GB (2 x 2GB) DS - - 8 1.65V · ·
KINGSTON KHX1600C9D3K2/4GX(XMP) 4GB (2 x 2GB) DS - - 9 1.65V · ·
KINGSTON KHX1600C9D3LK2/4GX(XMP) 4GB (2 x 2GB) DS - - 9 XMP
1.35V
·
KINGSTON KHX1600C9D3X2K2/4GX(XMP) 4GB (2 x 2GB) DS - - 9-9-9-27 1.65V · ·
KINGSTON KHX1600C9D3T1K3/6GX(XMP) 6GB ( 3x 2GB ) DS - - - 1.65V · ·
KINGSTON KHX1600C9D3K3/6GX(XMP) 6GB(3 x 2GB) DS - - 9 1.65V · ·
KINGSTON KHX1600C9D3T1BK3/6GX(XMP) 6GB(3 x 2GB) DS - - 9-9-9-27 1.65V · ·
KINGSTON KHX1600C9D3K2/8GX(XMP) 8GB(2 x 4GB) DS - - 9-9-9-27 1.65V · ·
KINGSTON KHX1600C9D3P1K2/8G 8GB(2 x 4GB) DS - - - 1.5V · ·
Super
Talent
WA160UX6G9 6GB(3 x 2GB) DS - - 9 - · ·
Transcend JM1600KLN-8GK 8GB(4GBx2) DS Transcend TK483PCW3 - - · ·
AMD AE32G1609U1-U 2GB SS - 23EY4587MB6H11503M 9-9-9-24 1.5V · ·
AMD AE34G1609U2-U 4GB DS AMD 23EY4587MB6H11503M 9-9-9-24 1.5V · ·
Asint SLZ302G08-EGN1C 4GB SS Asint SLZ302G08-GN1C - - ·
Asint SLZ3128M8-EGJ1D(XMP) 2GB DS Asint 3128M8-GJ1D 9-9-9-24 1.6V ·
Asint SLA302G08-EGG1C(XMP) 4GB DS Asint 302G08-GG1C - - · ·
Asint SLA302G08-EGJ1C(XMP) 4GB DS Asint 302G08-GJ1C - - · ·
ASint SLA302G08-EGN1C 4GB DS Asint SLA302G08-GN1C - - ·
ASint SLB304G08-EGN1B 8GB DS Asint SLB304G08-GN1B - - · ·
Elixir M2P2G64CB8HC9N-DG(XMP) 2GB DS - - - - · ·
Mushkin 998659(XMP) 6GB(3 x 2GB) DS - - 9-9-9-24 - · ·
Mushkin 998659(XMP) 6GB(3 x 2GB) DS - - 9-9-9-24 1.5~1.6V · ·
PATRIOT PGD316G1600ELK(XMP) 32GB(8GBx4) DS - - 9-9-9-24 1.65V · ·
PATRIOT PGS34G1600LLKA 4GB(2 x 2GB) DS - - 7-7-7-20 1.7V · ·
SanMax SMD-4G68HP-16KZ 4GB DS HYNIX H5TQ2G83BFR PBC - - ·
Silicon
Power
SP002GBLTU160V02(XMP) 2GB SS S-POWER 20YT5NG-1201 - - ·
Silicon
Power
SP004GBLTU160V02(XMP) 4GB DS S-POWER 20YT5NG-1201 - - · ·
DDR3-1600 MHz capability
(continued on the next page)

Asus P8H61-MX R2.0 Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 2000, 2133, 2200 MHz
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
Headphone outputs	3
USB 2.0 ports quantity	6
Audio chip	VIA VT1708S
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA, SATA II
Graphics card	HD Graphics
Maximum resolution	2048 x 1536 pixels
Parallel processing technology support	Not supported
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x16
Special features	2 x Thunderbolt
Cables included	SATA
LAN controller	Realtek RTL8111F
Networking features	Gigabit LAN
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	183 mm
Width	244 mm
