Asus P8H61-MX R2.0 User Manual

1-15Chapter 1: Product introduction
DDR3-2000 MHz capability
(continued on the next page)
DDR3-1866 MHz capability
Vendors Part No. Size SS/DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket
support (optional)
1DIMM 2DIMM
A-DATA
AX3U1866PB2G8-DP2(XMP) 2GB DS - - 8-8-8-24 1.55V-1.75V
CORSAIR CMT4GX3M2A1866C9(XMP) 4GB(2 x 2GB) DS - - 9-9-9-24 1.65V · ·
CORSAIR CMT6GX3MA1866C9(XMP) 6GB(3 x 2GB) DS - - 9-9-9-24 1.65V · ·
CORSAIR CMZ8GX3M2A1866C9(XMP) 8GB(2 x 4GB) DS - - 9-10-9-27 1.50V · ·
G.SKILL F3-14900CL9Q-16GBZL(XMP1.3) 16GB ( 4GB x4 ) DS - - 9-10-9-28 1.5V · ·
G.SKILL
F3-14900CL10Q2-
64GBZLD(XMP1.3)
64GB ( 8GBx 8 ) DS - - 10-11-10-30 1.5V · ·
G.SKILL F3-14900CL9D-8GBXL(XMP) 8GB(2 x 4GB) DS - - 9-10-9-28 1.5V · ·
G.SKILL F3-14900CL9Q-8GBXL(XMP) 8GB(2GBx4) DS - - 9-9-9-24 1.6V · ·
KINGSTON KHX1866C9D3T1K3/3GX(XMP) 3GB(3 x 1GB) SS - - - 1.65V · ·
KINGSTON KHX1866C9D3K4/16GX(XMP) 16GB ( 4GB x4 ) DS - - - 1.65V · ·
KINGSTON KHX1866C9D3T1K3/6GX(XMP) 6GB(3 x 2GB) DS - - - 1.65V · ·
KINGSTON KHX1866C11D3P1K2/8G 8GB ( 4GB x 2) DS - - - 1.5V · ·
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip NO. Timing Voltage
DIMM socket
support (optional)
1DIMM 2DIMMs
Apacer 78.AAGD5.9KD(XMP)
6GB (3 x
2GB)
DS - - 9-9-9-27 1.65V · ·
CORSAIR CMZ4GX3M2A2000C10(XMP)
4GB (2 x
2GB)
SS - - 10-10-10-27 1.50V · ·
CORSAIR CMT6GX3M3A2000C8(XMP)
6GB (3 x
2GB)
DS - - 8-9-8-24 1.65V · ·
G.SKILL F3-16000CL9D-4GBFLS(XMP)
4GB (2 x
2GB)
DS - - 9-9-9-24 1.65V · ·
G.SKILL F3-16000CL9D-4GBTD(XMP)
4GB (2 x
2GB)
DS - - 9-9-9-27 1.65V · ·
G.SKILL F3-16000CL6T-6GBPIS(XMP)
6GB (3x
2GB )
DS - - 6-9-6-24 1.65V · ·
GEIL GUP34GB2000C9DC(XMP)
4GB(2 x
2GB)
DS - - 9-9-9-28 1.65V · ·
KINGSTON KHX2000C9AD3T1K2/4GX(XMP)
4GB ( 2x
2GB )
DS - - - 1.65V · ·
KINGSTON
KHX2000C9AD3W1K2/
4GX(XMP)
4GB ( 2x
2GB )
DS - - - 1.65V · ·
KINGSTON KHX2000C9AD3T1K2/4GX(XMP)
4GB(2 x
2GB)
DS - - 9 1.65V · ·
KINGSTON
KHX2000C9AD3W1K3/
6GX(XMP)
6GB ( 3x
2GB )
DS - - - 1.65V · ·
KINGSTON KHX2000C9AD3T1K3/6GX(XMP)
6GB (3x
2GB )
DS - - - 1.65V · ·
Transcend TX2000KLN-8GK(XMP)
8GB(2 x
4GB)
DS - - - 1.6V · ·
PATRIOT PVT36G2000LLK
6GB
(3x2GB)
DS - - 8-8-8-24 1.65V
Asint SLA302G08-ML2HB(XMP) 4GB DS HYNIX H5TQ2G83BFR H9C - - · ·
DDR3-2133 MHz capability
Vendors Part No. Size SS/DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket
support (optional)
1DIMM 2DIMMs
A-DATA AX3U2133GC2G9B-DG2(XMP) 2GB SS - - 9-11-9-27 1.55~1.75V · ·
CORSAIR CMT16GX3M4X2133C9(XMP 1.3) 16GB ( 4GB x4 ) DS - - 9-11-10-27 1.50V · ·
CORSAIR CMT4GX3M2A2133C9(XMP) 4GB(2x 2GB) DS - - 9-10-9-24 1.65V · ·
CORSAIR CMT4GX3M2B2133C9(XMP) 4GB(2x 2GB) DS - - 9-10-9-27 1.50V · ·
CORSAIR CMT8GX3M2B2133C9(XMP) 8GB ( 4GB x 2) DS - - 9-11-9-27 1.50V · ·
G.SKILL F3-17000CL9Q-16GBZH(XMP1.3) 16GB ( 4GB x4 ) DS - - 9-11-10-28 1.65V · ·
GEIL GE34GB2133C9DC(XMP) 2GB DS - - 9-9-9-28 1.65V · ·
GEIL GU34GB2133C9DC(XMP) 4GB(2 x 2GB) DS - - 9-9-9-28 1.65V · ·
KINGSTON KHX2133C9AD3T1K2/4GX(XMP) 4GB ( 2x 2GB ) DS - - - 1.65V · ·
KINGSTON KHX2133C9AD3X2K2/4GX(XMP) 4GB(2 x 2GB) DS - - 9-11-9-27 1.65V · ·
KINGSTON KHX2133C9AD3T1K4/8GX(XMP) 8GB(4 x 2GB) DS - - 9-11-9-27 1.65V · ·
KINGSTON KHX2133C9AD3T1FK4/8GX(XMP) 8GB(4x 2GB) DS - - - 1.65V · ·

Asus P8H61-MX R2.0 Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 2000, 2133, 2200 MHz
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
Number of SATA II connectors	4
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
Headphone outputs	3
USB 2.0 ports quantity	6
Audio chip	VIA VT1708S
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H61
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA, SATA II
Graphics card	HD Graphics
Maximum resolution	2048 x 1536 pixels
Parallel processing technology support	Not supported
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x16
Special features	2 x Thunderbolt
Cables included	SATA
LAN controller	Realtek RTL8111F
Networking features	Gigabit LAN
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	183 mm
Width	244 mm
