ASUS Motherboard installation guide 1-19
1.7.2 SATA optical disk drive
1. Remove the dummy cover and
slide the optical disk drive into the
bay.
2. Align with the screw holes and
secure the disk drive with screws.
3. Orient and plug the SATA cable into
the optical drive. SATA cables are
dummy-proof. Never force a SATA
cable into the connector.
4. Connect the SATA power cable to
the the optical drive.
5. Attach the audio cable to the
connector on the optical drive.
