Asus P8H61 User Manual

1-2 Chapter 1: Quick Start
6. Apply some Thermal Interface
Material to the exposed area of
the CPU that the heatsink will be
in contact with, ensuring that it is
spread in an even thin layer.
Some heatsinks come with pre-
applied thermal paste. If so, skip
this step.
7. Close the load plate (A), then push
the load lever (B) until it snaps into
the retention tab.
A
B
The Thermal Interface Material is
toxic and inedible. DO NOT eat it.
If it gets into your eyes or touches
your skin, wash it off immediately,
and seek professional medical
help.

Asus P8H61 Specifications

General

Form Factor	ATX
Chipset	Intel H61
CPU Socket	LGA 1155
Memory Type	DDR3
Memory Slots	2
Maximum Memory	16 GB
Expansion Slots	1 x PCIe 2.0 x16, 2 x PCIe 2.0 x1, 1 x PCI
Storage Interface	4 x SATA 3Gb/s
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
LAN	Realtek 8111E
USB Ports	10 x USB 2.0
