ASUS P8H67-M2 Series1-2
P8H67-M2/TPM/SI
PCIEX16
PCI1
PCI2
PCIEX1_1
LPT
COM1
USB1314 USB1112 USB910 USB78 F_PANEL
C
LR
T
C
C
H
A
S
S
IS
AAFP
ATX12V
EATXPWR
CPU_FAN
CHA_FAN
Lithium Cell
CMOS Power
Super
I/O
VIA
VT1708S
RTL
8111E
EPU
32Mb
BIOS
asmedia
ASM1083
SB_PWR
SPDIF_OUT
24.4cm(9.6in)
LGA1155
Intel
®
H67
DDR3 DIMM_B1 (64bit, 240-pin module) DDR3 DIMM_B2 (64bit, 240-pin module) DDR3 DIMM_A1 (64bit, 240-pin module) DDR3 DIMM_A2 (64bit, 240-pin module)
SATA6G_2SATA3G_2
SATA6G_1SATA3G_1
SATA3G_4
SATA3G_3
AUDIO
KB_USB56
LAN1_USB12
USB34
22.4cm(8.8in)
VGA
DVI
SPEAKER
TPM IC
321 41 5
10
7
8
9
2
6
13141516 12 11
Place six screws into the holes indicated by circles to secure the motherboard to the
chassis. DO NOT overtighten the screws! Doing so can damage the motherboard.
Ensure that you install the motherboard into the chassis in the correct orientation. The edge
with external ports goes to the rear part of the chassis.
1.2 Motherboard overview
1.2.1 Motherboard layout
