P8H77-I specications summary
(continued on the next page)
CPU LGA1155 Socket for Intel
®
3rd/2nd Generation Core™ i7 / i5 / i3 /
Pentium
®
/ Celeron
®
Processors
Supports Intel® Turbo Boost Technology 2.0*
*The Turbo Boost Technology 2.0 support depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset Intel
®
H77 Express Chipset
Memory 2 x U-DIMM, maximum 16GB*, DDR3 2200(O.C.)/2133(O.C.)/2200(O.
C.)/2000(O.C.)/1866(O.C.)/1800(O.C.)/1600/1333/1066 MHz, non-
ECC, un-buffered memory
Dual-channel memory architecture
* DDR3 1600 MHz and above memory frequency is supported by
Intel
®
3rd generation processors.
** The maximum 16GB memory capacity can be supported with
8GB or above DIMMs. ASUS will update the memory QVL
once the DIMMs are available in the market.
*** Refer to www.asus.com for the latest Memory QVL (Qualied
Vendors List).
**** When you install a total memory of 4GB capacity or more,
Windows
®
32-bit operating system may only recognize less than
3GB. We recommend a maximum of 3GB system memory if you are
using a Windows
®
32-bit operating system.
Expansion slots 1 x PCI Express 3.0/2.0 x16 slot
* This motherboard is ready to support PCIe 3.0 SPEC. Functions will
be available when using PCIe 3.0-compliant devices. Please refer
to www.asus.com for updated details.
Graphics Supports HDMI with max. resolution up to 1920 x 1200 @60Hz
Supports DVI with max. resolution up to 1920 x 1200 @60Hz
Supports D-Sub with max. resolution up to 2048 x 1536 @75Hz
Storage Intel
®
H77 Express Chipset:
- 2 x Serial ATA 6.0 Gb/s connectors (gray)
- 4 x Serial ATA 3.0 Gb/s connectors (blue)
- Support RAID 0, 1, 5, 10 Mode
LAN
Realtek
®
RTL8111F Gigabit LAN controller
Audio VIA® 8-channel High Denition Audio CODEC
- Supports Multi-Streaming, and Front Panel Jack-Retasking
USB 4 x USB 3.0 ports (2 ports at mid-board, 2 ports at back panel)
8 x USB 2.0/1.1 ports (2 ports at mid-board, 6 ports at back panel)
Back Panel I/O
Ports
1 x PS/2 Keyboard/Mouse port
1 x HDMI Output port
1 x DVI-D Output port
1 x D-SUB Output port
1 x LAN (RJ45) port
2 x USB 3.0 ports
6 x USB 2.0/1.1 ports
1 x Optical S/PDIF Out
3 x Audio jack(s)

Asus P8H77-I Specifications

General

ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
Number of SATA II connectors	4
Number of Parallel ATA connectors	0
Headphone outputs	3
USB 2.0 ports quantity	6
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	LucidLogix Virtu
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x16
Bluetooth	No
LAN controller	Realtek RTL8111F
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Width	170 mm
