Asus P8H77-M User Manual

ASUS P8H77-M 1-17
DDR3-2250MHz capability
DDR3-2200MHz capability
P8H77-M Motherboard Qualied Vendors List (QVL)
DDR3-2400MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket support (Optional)
1 DIMM 2 DIMMs 4 DIMMs
CORSAIR CMGTX8(XMP) 8GB (2GBx4) SS - - 10-12-10-27 1.65V • • •
G.SKILL
F3-19200CL11Q-
16GBZHD(XMP)
16GB (4x4GB) DS - - 11-11-11-31 1.65V • •
G.SKILL F3-19200CL9D-4GBPIS(XMP) 4GB (2x2GB) DS - - 9-11-9-28 1.65V • • •
GEIL GET34GB2400C9DC(XMP) 2GB DS - - 9-11-9-27 1.65V • • •
KINGMAX FLLE88F-C8KKAA HAIS(XMP) 2GB SS - - 10-11-10-30 1.8V • • •
Transcend TX2400KLU-4GK(427652)(XMP) 4GB (2x2GB) SS - - - 1.65V • • •
Transcend TX2400KLU-4GK (381850)(XMP) 4GB (2x2GB) SS - - 9 1.65V • • •
Transcend TX2400KLU-4GK(374243)(XMP) 4GB (2x2GB) DS - - 9 1.65V • • •
PATRIOT PVV34G2400C9K(XMP) 4GB (2x2GB) DS - - 9-11-9-27 1.65V • •
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
KINGMAX KHX2250C9D3T1K2/4GX(XMP) 4GB (2x2GB) DS - - - 1.65V • • •
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
G.SKILL F3-17600CL8D-4GBPS(XMP)
4GB
(2X2GB)
DS - - 8-8-8-24 1.65V
GEIL GET34GB2200C9DC(XMP) 2GB DS - - 9-10-9-28 1.65V • • •
GEIL GET38GB2200C9ADC(XMP) 4GB DS - - 9-11-9-28 1.65V •
KINGMAX FLKE85F-B8KJAA-FEIS(XMP) 2GB DS - - - - • • •
KINGMAX FLKE85F-B8KHA EEIH(XMP)
4GB
(2X2GB)
DS - - - 1.5V-1.7V •
KINGMAX FLKE85F-B8KJA FEIH(XMP) 4GB (2x2GB) DS - - - 1.5V-1.7V • • •
DDR3-2133MHz capability
Vendors Part No. Size
SS/
DS
Chip
Brand
Chip
NO.
Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMMs 4 DIMMs
A-DATA AX3U2133GC2G9B-DG2(XMP) 2GB SS - - 9-11-9-27 1.55-1.75V • • •
CORSAIR
CMT16GX3M4X2133C9(XMP
1.3)
16GB
(4x4GB)
DS - - 9-11-10-27 1.50V • • •
CORSAIR CMT4GX3M2A2133C9(XMP) 4GB (2x2GB) DS - - 9-10-9-24 1.65V • • •
CORSAIR CMT4GX3M2B2133C9(XMP) 4GB (2GBx2) DS - - 9-10-9-27 1.5V • • •
G.SKILL F3-17000CL9Q-16GBZH(XMP)
16GB
(4GBx4)
DS - - 9-11-10-28 1.65V • • •
GEIL GE34GB2133C9DC(XMP) 2GB DS - - 9-9-9-28 1.65V • •
GEIL GU34GB2133C9DC(XMP) 4GB (2x2GB) DS - - 9-9-9-28 1.65V • • •
KINGSTON
KHX2133C9AD3T1K2/
4GX(XMP)
4GB (2x2GB) DS - - - 1.65V • • •
KINGSTON
KHX2133C9AD3X2K2/
4GX(XMP)
4GB (2x2GB) DS - - 9-11-9-27 1.65V • • •
KINGSTON
KHX2133C9AD3T1K4/
8GX(XMP)
8GB (4x2GB) DS - - 9-11-9-27 1.65V • • •
KINGSTON
KHX2133C9AD3T1FK4/
8GX(XMP)
8GB (4x2GB) DS - - - 1.65V • • •

Asus P8H77-M Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	16GB, 1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	2
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	2-Way CrossFireX, LucidLogix Virtu, Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16
LAN controller	Realtek RTL8111F
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Width	245 mm
