2.3.10 Rear panel connection
Rear panel connectors
1. PS/2 mouse and keyboard port 7. USB 2.0 ports 5 and 6
2. Coaxial S/PDIF Out port 8. Optical S/PDIF Out port
3. LAN (RJ-45) port 2* 9. USB 2.0 ports 3 and 4
4. IEEE 1394a port 10. USB 2.0 ports 1 and 2
5. LAN (RJ-45) port 1* 11. USB 3.0 ports 1 and 2
6. USB 2.0 ports 7 and 8 12. Audio I/O ports**
2-40 Chapter 2: Hardware information
