ASUS P9D-I
5-11
Using New Conguration
When a RAID set already exists, using the
New Conguration
command erases the
existing RAID configuration data. If you do not want to delete the existing RAID set, use the
View/Add Conguration
command to view or create another RAID configuration.
To create a RAID set using the New Conguration option:
1. From the Management Menu
, select Congure > New Conguration then press
<Enter>.
2. Select Yes then press <Enter> to proceed with the configuration.
3. Select all the drives required for the RAID set then press <F10> to configure array
setting.
SPACE-Sel,ENTER-EndArray,F10-Configure,F2-Drive Info,F3-Virtual Drives,F4-HSP
LSI Software RAID Configuration Utility Ver C.05 Oct 26,2011
BIOS Version A.11.02090932R
Port # 2 DISK 74.74GB HDS728080PLA380 05.01C05
Configure
Initialize
Objects
Rebuild
Check Consistency
Management Menu
Easy Configuration - ARRAY SELECTION MENU
ONLIN A00-00
ONLIN A00-01
READY
READY
0
1
2
3
PORT #
Use Cursor Keys To Navigate Between Items And Press Enter To Select An Option
LSI Software RAID Configuration Utility Ver C.05 Oct 26,2011
BIOS Version A.11.02090932R
Clear Existing Configuration And Start A New Configuration
Configure
Initialize
Objects
Rebuild
Check Consistency
Management Menu
Easy Configuration
New Configuration
View/Add Configuration
Clear Configuration
Select Boot Drive
Configuration Menu
