16
ASUS A7V User’s Manual
3. HARDWARE SETUP
Layout Contents
3. H/W SETUP
18) USB3A, USBPORT, p. 41 USB Headers (5-1 pins / 10-1 pins)
USB3
19) SMB p. 41 SMBus Connector (5-1 pins)
20) ATXPWR p. 42 ATX Power Supply Connector (20 pins)
21) JTPWR p. 42 Power Supply Thermal Sensor Connector (2 pins)
22) IDELED p. 43 IDE Activity LED (2 pins)
23)
PWR.LED ( PANEL ) p. 44 System Power LED Lead (3 pins)
24) SPEAKER (PANEL) p. 44 System Warning Speaker Connector (4 pins)
25) MSG.LED (PANEL) p. 44 System Message LED (2 pins)
26) SMI (PANEL) p. 44 System Management Interrupt Lead (2 pins)
27) PWR.SW (PANEL) p. 44 ATX / Soft-Off Switch Lead (2 pins)
28) RESET (PANEL) p. 44 Reset Switch Lead (2 pins)
