ASUS A7V User’s Manual 15
3. HARDWARE SETUP
3.2 Layout Contents
Motherboard Settings
1) JEN p. 18 JumperFree Mode (JumperFree/Jumper Mode)
2) AUDIOCODEC p. 19 Onboard Audio Setting (Enable/Enable)
3) 3VSBSLT p. 20 PCI 3Volt Setting (3 Volt/3 VSB)
4) VIO p. 21 I/O Voltage Setting (3.35 Volt/3.56 Volt/3.69 Volt)
5) DSW 1–4 p. 22 CPU External Frequency Setting
6) DSFID 1–4 p. 23 CPU Core: BUS Frequency Multiple
7) VID1/VID2/VID3/VID4 p. 24 Voltage Regulator Output Setting
Expansion Slots/Sockets
1) System Memory p.24 System Memory Support
2) DIMM1/2/3 p.25 DIMM Memory Module Support
3) Socket 462 (Socket A) p.27 CPU Support
4) PCI1/2/3/4/5 p.29 32-bit PCI Bus Expansion Slots
5) AGP PRO p.31 Accelerated Graphics Port (AGP) Pro
6) AMR p.32 Audio Modem Riser (AMR) Slot
Connectors
1) PS2KBMS p.33 PS/2 Mouse Port Connector (6 pin-female)
2) PS2KBMS p.33 PS/2 Keyboard Port Connector (6-pin female)
3) USB p.34 Universal Serial Bus Connectors 0 & 1 (Two 4-pin female)
4) COM1/COM2 p.34 Serial Port Connector (9-pin male)
5) PRINTER p.34 Parallel Port Connector (25-pin female)
6) GAME_AUDIO p.35 Game/MIDI Connector (15-pin female) (optional)
7) GAME_AUDIO p.35 Audio Port Connectors (Three 1/8” female) (optional)
8) FLOPPY p.35 Floppy Disk Drive Port Connector (34 pins)
9) PRIMARY IDE p.36 IDE Connectors (Four 40-1 pins)
SECONDARY IDE
PRIMARY ATA100
SECONDARY ATA100
10) CHASSIS p. 37 Chassis Intrusion Lead (4-1 pins)
11) IR p. 37 Infrared Module Connector (5 pins)
12) WOL_CON p. 38 Wake-On-LAN Connector (3 pins)
13) WOR p. 38 Wake-On-Ring Connector (2 pins)
14) PWR_, CPU_,CHA_FAN p. 39 Chassis, Power Supply, CPU, F_ Fan Connectors (3 pins)
F_FAN
15) CD_IN, AUX, VIDEO p. 40 Internal Audio Connectors (4 4-pin)
MODEM
16) MIC2 p. 40 Internal Microphone Header (3 pins)
17) HPHONE p. 40 Headphone True-Level Out Header (3 pins)
Layout Contents
3. H/W SETUP
continued...
To Next Page
