ASUS PRIME B350M-E
1-3
CPU_FAN
CPU FAN PWM
CPU FAN IN
CPU FAN PWR
GND
CHA_FAN
GND
CHA FAN PWR
CHA FAN IN
CHA FAN PWM
Donotforgettoconnectthefancablestothefan
connectors.Insufcientairowinsidethesystemmay
damage the motherboard components. These are not
jumpers!Donotplacejumpercapsonthefanconnectors!
TheCPU_FANconnectorsupportsaCPUfanof
maximum1A(12W)fanpower.
5. M.2 socket 3
ThesesocketsallowyoutoinstallM.2(NGFF)SSDmodules.
M.2(SOCKET3)
• ThissocketsupportsMKeyand2242/2260/2280storage
devices.
• DuetoCPUlimitation,M.2socketsupportedvariesby
processor.Refertothespecicationssummarytableformore
details.
4. DDR4 DIMM slots
Install2GB,4GB,8GB,and16GBunbufferedECCandnon-ECCDDR4DIMMsinto
theseDIMMsockets.
Formoredetails,refertoSystem memory.
3. AMD AM4 CPU socket
ThismotherboardcomeswithaAMDAM4socketdesignedforAMDRyzen™/7th
GenerationA-series/Athlon™processors.
Formoredetails,refertoCentral Processing Unit (CPU).
6. AMD B350 SATA 6.0Gb/s ports (7-pin SATA6G_1~4)
TheseportsconnecttoSATA6.0Gb/sharddiskdrivesviaSATA
6.0Gb/ssignalcables.
GND
RSATA_TXP
RSATA_TXN
GND
RSATA_RXN
RSATA_RXP
GND
SATA6G
