1-6
Chapter 1: Product introduction
15. PCI Express 2.0 x1 slots
ThismotherboardhastwoPCIExpress2.0x1slotsthatsupportPCIExpressx1
networkcards,SCSIcards,andothercardsthatcomplywiththePCIExpress
specications.
16. PCI Express x16 slot
ThismotherboardsupportsonePCIExpressx16graphiccardthatcomplieswiththe
PCIExpressspecications.
A B C D E F G H
PCIEx16_1 – – – shared – – – –
PCIEx1_1 shared – – – – – – –
PCIEx1_2 – – – shared – – – –
M.2 – – – shared – – – –
APUUSB3.1Gen1XHCI
controller
– – shared – – – – –
AMDPromonotryChip
XHCIcontroller
shared – – – – – – –
SATAcontroller – – – shared – – – –
HDaudiocontroller – – – – – – shared –
RealtekLANcontroller – – shared – – – – –
IRQ assignments for this motherboard
• ForAMDsocketAM4A-series/Athlon
TM
Series processors:
• Werecommendthatyouconnectahigh-denitionfrontpanelaudiomoduletothis
connectortoavailofthemotherboard’shigh-denitionaudiocapability.
• Ifyouwanttoconnectahigh-denitionfrontpanelaudiomoduletothisconnector,set
the Front Panel TypeitemintheBIOSsetupto[HD].IfyouwanttoconnectanAC’97
frontpanelaudiomoduletothisconnector,settheitemto[AC97].Bydefault,this
connectorissetto[HD].
