ROG MAXIMUS X APEX

1-7

Chapter 1

1.1.5 Expansion slots

Unplugthepowercordbeforeaddingorremovingexpansioncards.Failuretodosomay

causeyouphysicalinjuryanddamagemotherboardcomponents.

Slot No. Slot Description

1 PCIeX16/X8_1slot

2 PCIeX4_2slot

3 PCIeX1_1slot

4 PCIeX8/X4_3slot

5 PCIeX1_2slot

6 PCIeX4_4slot
