1-18

Chapter 1: Product Introduction

Chapter 1

3. Q-Code LED

TheQ-CodeLEDdesignprovidesyouwitha2-digiterrorcodethatdisplaysthesystem

status.

• TheQ-CodeLEDprovidesthemostprobablecauseofanerrorcodeasastarting

pointfortroubleshooting.Theactualcausemayvaryfromcasetocase.

• PleaserefertotheQ-CodetableintheAppendixsectionformoredetails.
