Chapter 3: BIOS Setup

Chapter 3

Configuring fans manually

Select Manual from the list of proles to manually congure your fans’ operating speed.

To congure your fans:

1. Select the fan that you want to congure and to view its current status.

2. Click and drag the speed points to adjust the fans’ operating speed.

3. Click Apply to save the changes then click Exit (ESC).

Speed points

Select to manually

configure your fans
