2.1.8 Front I/O connector
To install USB 3.2 Gen 2 connectorTo install ASUS Q-Connector
This connector will only fit in one
orientation. Push the connector until it
clicks into place.
USB 2.0
AAFP
To install USB 2.0 connector
To install front panel audio connector
USB 3.2 Gen 1
To install USB 3.2 Gen 1 connector
To install system speaker connector
USB 3.2 Gen 2
