2-2
Chapter 3: General Instruction
2.2 Detaching the arm/stand (for VESA wall
mount)
• Avoid damaging the monitor surface. While detaching the monitor
stand, always keep the monitor inside its EPS packaging.
The detachable stand of this monitor is specially designed for VESA wall
mount.
To detach the arm/stand
1. Disconnect power and signal cables. Carefully put the monitor
facedown on its EPS packaging.
2. Remove the covers on where the monitor and the arm meet.
3. Remove the four (4) screws securing the arm to the rear of the
monitor.
4. Detach the stand (arm and base) from the monitor.
• The VESA wall mount kit ( 100 x 100 mm) is purchased separately.
• Use only the UL Listed Wall Mount Bracket with minimum weight/load
28.8 kg (Screw size: M4 x 10 mm).
