ROG STRIX Z390-E GAMING
2-9
Chapter 2
2.1.7 Front I/O connector
USB 3.1 Gen 2
To install USB 3.1 Gen 2 connector
Thisconnectorwillonlytinone
orientation.Pushtheconnectoruntilit
clicksintoplace.
USB 2.0
AAFP
To install USB 2.0 connector To install front panel audio connector
USB 3.1 Gen 1
To install USB 3.1 Gen 1 connector
